▶ EngineEngine Manufacturer Mitsubishi TYM Engine Model MVL3E3 A1100N2 Engine Type Four Stroke, Naturally Aspirated, Indirect Injection, Water-Cooled Diesel 3 cylinder, water-cooled diesel, natural aspiration, swirl chamber No. of Cylinders 3 3 Displacement 67.2 in³ 71.7 in³ Rated Engine Speed 3000 rpm 2600 rpm Engine Power (Gross) 25.3 hp 25 hp PTO Power 19.2 hp 18 hp Engine Emissions Constraints No DPF Tier 4 Cooling System Type Water-Cooled Water-cooled Air Cleaner Not Published Dry element Fuel System Indirect Injection Indirect injection (swirl chamber) Alternator 55 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Not Published Gear type pump with primary and secondary pumps Implement Flow 7.6 gpm 4.3 gpm Steering Flow 3.8 gpm 3.1 gpm Total Hydraulic Flow 11.2 gpm 7.4 gpm Overall Hydraulic Pump Flow 11.2 gpm 7.7 gpm Hydraulic System Type Open Center, full-live hydraulic with position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Single or dual 1 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.08 gal Coolant Capacity Not Published 1.21 gal Crankcase Capacity Not Published 0.79 gal Transmission / Hydraulic System Capacity Not Published 2.90 gal Front Axle Fluid Capacity Not Published 0.79 gal ▶ PTO & HitchPTO Type Independent Wet Clutch Live PTO (6 spline shaft) PTO Rear 540 rpm @ 2837 rpm 540 / 960 rpm Mid-PTO Availability Optional; 2500 rpm @ 2837 rpm Optional, 2,500 rpm Category, 3-Point Hitch CAT I with check chains Category I Hitch Lift Capacity Not Published 1,433 lb Hitch Lift Capacity (at 24”) 771 lb 974 lb Lift Control Type Position Control Position control ▶ Transmission & DrivetrainTransmission Type HST - 2 Range Hydrostatic (HST) No. of Speeds Infinite 3 range (L/M/H) Max Travel Speed (Forward) 7.3 mph 14.8 mph Max Travel Speed (Reverse) Not Published 14.8 mph Clutch Not Published Dry, single plate Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Steel frame with cast iron axles Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Single Pedal Wet disc Seat Suspension & Adjustability Not Published Adjustable seat, flips up and back for rear backhoe operation Front Axle Type Not Published Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 46.3 in 53.8 in Wheelbase 55.1 in 65.7 in Ground Clearance 6.7 in 16.4 in Min. Turn Radius without Brakes 7.2 ft (with brake applied) Not Published Height to Top of ROPS 86.6 in 91.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 100.4 in 110 in ▶ WeightTractor Weight (Base) 1,620 lb (operating weight) 2,106 lb Weight with ROPS and Loader 2,026 lb (1,620 + 406, computed; L11 loader shipping weight) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Industrial, Turf R4 Industrial (25x8.50-14 front / 14x17.5 rear) R1 Agricultural - Front Not Published 7-16 6PR R1 Agricultural - Rear Not Published 11.2-20 R3 Turf - Front 18x8.5-10 Not Published R3 Turf - Rear 26x12-12 Not Published R4 Industrial - Front 18x8.5-10 25x8.50-14 R4 Industrial - Rear 26x12-12 14x17.5 ▶ Loader & AttachmentsQuick Attach Loader System L11: Front loader skid-steer couplers for superfast hookups Quick attach front loader Loader Model L11 BBL300 Loader Lift Height L11: 68 in 86 in Loader Lift Capacity (Full Height) L11: 794 lb; Measured at: pivot pin, full height 1,314 lb (at pivot pin) Loader Breakout Force L11: 1,433 lb 1,960 lbf ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
