▶ EngineEngine Manufacturer Mitsubishi Kubota Engine Model MVL3E3 D1703-M-DI-E4 Engine Type Four Stroke, Naturally Aspirated, Indirect Injection, Water-Cooled Diesel Direct injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 67.2 in³ 100.47 in³ Rated Engine Speed 3000 rpm 2200 rpm Engine Power (Gross) 25.3 hp 24.8 hp PTO Power 19.2 hp 19 hp Engine Emissions Constraints No DPF Tier 4 Cooling System Type Water-Cooled Water-cooled Air Cleaner Not Published Dry paper single element (dual optional) Fuel System Indirect Injection Direct injection Alternator 55 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump, gear type Implement Flow 7.6 gpm 5.15 gpm Steering Flow 3.8 gpm 3.11 gpm Total Hydraulic Flow 11.2 gpm 8.26 gpm Overall Hydraulic Pump Flow 11.2 gpm 8.26 gpm Hydraulic System Type Open Center, full-live hydraulic with position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Single or dual Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 10.0 gal Coolant Capacity Not Published 6.3 qt Crankcase Capacity Not Published 6.0 qt Transmission / Hydraulic System Capacity Not Published HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal Front Axle Fluid Capacity Not Published 6.9 qt ▶ PTO & HitchPTO Type Independent Wet Clutch F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running PTO Rear 540 rpm @ 2837 rpm 540 rpm Mid-PTO Availability Optional; 2500 rpm @ 2837 rpm No mid-PTO offered Category, 3-Point Hitch CAT I with check chains Category I Hitch Lift Capacity Not Published 1,918 lb Hitch Lift Capacity (at 24”) 771 lb 1,389 lb Lift Control Type Position Control Position control ▶ Transmission & DrivetrainTransmission Type HST - 2 Range Hydrostatic transmission (3-range) No. of Speeds Infinite 3-range Max Travel Speed (Forward) 7.3 mph 11.5 mph Max Travel Speed (Reverse) Not Published 10.3 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Integral type power steering Brakes Single Pedal Wet disc type Seat Suspension & Adjustability Not Published Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Not Published Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published 2,865 lb (4WD, at 43.1 in tread) Drawbar Capacity Not Published 730 lb ▶ Dimensions & ManeuverabilityOverall Width 46.3 in 55.1 in Wheelbase 55.1 in 63.3 in Ground Clearance 6.7 in 13.4 in Min. Turn Radius without Brakes 7.2 ft (with brake applied) 8.2 ft (with brake applied) Height to Top of ROPS 86.6 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 100.4 in 106.3 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 1,620 lb (operating weight) 2,623 lb Weight with ROPS and Loader 2,026 lb (1,620 + 406, computed; L11 loader shipping weight) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Industrial, Turf R1 Agricultural; R4 Industrial R1 Agricultural - Front Not Published 7.2-16 R1 Agricultural - Rear Not Published 11.2-24 R3 Turf - Front 18x8.5-10 Not Published R3 Turf - Rear 26x12-12 Not Published R4 Industrial - Front 18x8.5-10 27X8.50-15 R4 Industrial - Rear 26x12-12 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System L11: Front loader skid-steer couplers for superfast hookups Front Loader (LA525 - 2 Lever Quick Coupler) Loader Model L11 LA525 Loader Lift Height L11: 68 in 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) L11: 794 lb; Measured at: pivot pin, full height 1,082 lb (at pivot pin) Loader Breakout Force L11: 1,433 lb 2,373 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
