Mahindra 1126 HST Cab vs Kubota L2501 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Every published spec, side by side, including the details the graphs above don't chart.
Spec
Mahindra1126 HST Cab
KubotaL2501
Engine Manufacturer
Mitsubishi
Kubota
Engine Model
MVL3E3
D1703-M-DI-E4
Engine Type
Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine
Direct injection, vertical, water-cooled, 4-cycle diesel
No. of Cylinders
3
3
Displacement
67.2 in³
100.47 in³
Rated Engine Speed
3000 rpm
2200 rpm
Engine Power (Gross)
25.3 hp
24.8 hp
PTO Power
19.2 hp
19 hp
Engine Emissions Constraints
Not Published
Tier 4
Cooling System Type
Water-Cooled
Water-cooled
Air Cleaner
Not Published
Dry paper single element (dual optional)
Fuel System
Indirect Injection
Direct injection
Alternator
55 A, 12 V
40 A, 12 V
Pump Type
Not Published
Open center tandem pump, gear type
Implement Flow
7.6 gpm
5.15 gpm
Steering Flow
3.8 gpm
3.13 gpm
Total Hydraulic Flow
11.2 gpm
8.26 gpm
Overall Hydraulic Pump Flow
11.2 gpm
8.26 gpm
Hydraulic System Type
Open Center, full-live hydraulic with position control
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
No. of Standard Remote Valves
Not Published
Not Published
No. of Optional Remote Valves
Single or dual
Up to 3 (self canceling detent valve or float detent valve options)
Fuel Tank Capacity
6.6 gal
10.0 gal
Coolant Capacity
Not Published
6.3 qt
Crankcase Capacity
Not Published
6.0 qt
Transmission / Hydraulic System Capacity
Not Published
6.2 gal
Front Axle Fluid Capacity
Not Published
4.8 qt
PTO Type
Independent Wet Clutch
Live-continuous running
PTO Rear
540 rpm @ 2837 rpm
540 rpm
Mid-PTO Availability
Optional; 2500 rpm @ 2837 rpm
No mid-PTO offered
Category, 3-Point Hitch
CAT 1 with check chains
Category I
Hitch Lift Capacity
Not Published
1918 lb
Hitch Lift Capacity (at 24”)
771 lb
1389 lb
Lift Control Type
Position Control
Position control
Transmission Type
HST - 2 Range
Hydrostatic transmission (3-range)
No. of Speeds
Infinite forward and reverse (2 ranges)
3-range
Max Travel Speed (Forward)
7.3 mph
11.5 mph
Max Travel Speed (Reverse)
Not Published
10.3 mph
Clutch
Not Published
Not Applicable
Differential Lock & Limited Slip Options
Not Published
Rear differential lock standard
Frame Type
Not Published
Not Published
Steering
Hydrostatic Power Steering
Integral type power steering
Brakes
Single Pedal
Wet disc type
Seat Suspension & Adjustability
Not Published
Suspension seat with fore/aft travel adjustment and suspension tension adjustment
Front Axle Type
Not Published
Bevel gear front axle, non-adjustable tread spacing
Front Axle Rating
Not Published
2865 lb (at 43.1 in tread)
Drawbar Capacity
Not Published
730 lb
Overall Length with 3-Point Hitch
100.4 in
106.3 in (without 3-point hitch)
Overall Width
46.3 in
55.1 in
Wheelbase
55.1 in
63.3 in
Ground Clearance
6.7 in
13.4 in
Min. Turn Radius without Brakes
7.2 ft (with brake applied)
8.2 ft (with brake applied)
Height to Top of ROPS
Not Published
91.7 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
80.5 in
Not Published
Tractor Weight (Base)
1962 lb
2623 lb
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
2368 lb
Not Published
Tire Size & Options
R3 Turf, R4 Industrial
R1 Agricultural; R4 Industrial
R1 Agricultural - Front
Not Published
7.2-16
R1 Agricultural - Rear
Not Published
11.2-24
R3 Turf - Front
18x8.5-10
Not Published
R3 Turf - Rear
26x12-12
Not Published
R4 Industrial - Front
18x8.5-10
27X8.50-15
R4 Industrial - Rear
26x12-12
15-19.5
Quick Attach Loader System
L11: Front loader skid-steer couplers for superfast hookups
Front Loader (LA525 - 2 Lever Quick Coupler)
Loader Model
L11
LA525
Loader Lift Height
L11: 68 in
94.3 in
Loader Lift Capacity (Full Height)
L11: 794 lb
1131 lb
Loader Breakout Force
L11: 1433 lb
2373 lbf
Warranty Length & Coverage
7-Year Limited Powertrain Warranty
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
