▶ EngineEngine Manufacturer Mitsubishi Kubota Engine Model S3L2 D1703-M-DI-E4 Engine Type Tier IV, four-cycle, valve in cylinder head, naturally aspirated, indirect-injection, water-cooled diesel Direct injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 80.4 in³ 100.47 in³ Rated Engine Speed 2500 rpm 2200 rpm Engine Power (Gross) 25.6 hp 24.8 hp PTO Power 19 hp 19 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Dry paper single element (dual optional) Fuel System Not Published Direct injection Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump, gear type Implement Flow 7.5 gpm 5.15 gpm Steering Flow 3.3 gpm 3.11 gpm Total Hydraulic Flow 10.8 gpm (7.5 + 3.3, computed) 8.26 gpm Overall Hydraulic Pump Flow Not Published 8.26 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 10.0 gal Coolant Capacity Not Published 6.3 qt Crankcase Capacity Not Published 6.0 qt Transmission / Hydraulic System Capacity Not Published HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal Front Axle Fluid Capacity Not Published 6.9 qt ▶ PTO & HitchPTO Type Independent (1526 Shuttle); Live (1526 HST) F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional; 2000 rpm No mid-PTO offered Category, 3-Point Hitch CAT I with telescopic stabilizers Category I Hitch Lift Capacity 2,646 lb 1,918 lb Hitch Lift Capacity (at 24”) Not Published 1,389 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Constant mesh on gear shift, synchro mesh on F/R shuttle (1526 Shuttle); 3 range HST (1526 HST) Hydrostatic transmission (3-range) No. of Speeds 8F/8R (1526 Shuttle); Infinite, 3 ranges (1526 HST) 3-range Max Travel Speed (Forward) Not Published 11.5 mph Max Travel Speed (Reverse) Not Published 10.3 mph Clutch Single plate, dry Not Published Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Integral type power steering Brakes Wet disc Wet disc type Seat Suspension & Adjustability Deluxe suspension seat Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Not Published Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published 2,865 lb (4WD, at 43.1 in tread) Drawbar Capacity Not Published 730 lb ▶ Dimensions & ManeuverabilityOverall Width 63 in 55.1 in Wheelbase Not Published 63.3 in Ground Clearance Not Published 13.4 in Min. Turn Radius without Brakes 7.9 ft 8.2 ft (with brake applied) Height to Top of ROPS 81.5 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 121.3 in (with industrial tires) 106.3 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,437 lb (1526 Shuttle, operating weight); 2,459 lb (1526 HST, operating weight) 2,623 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Turf R1 Agricultural; R4 Industrial R1 Agricultural - Front 7x16 7.2-16 R1 Agricultural - Rear 11.2x24 11.2-24 R3 Turf - Front 25x8.5-14 Not Published R3 Turf - Rear 13.6x16 Not Published R4 Industrial - Front 27x8.5-15 27X8.50-15 R4 Industrial - Rear 15x19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Front Loader (LA525 - 2 Lever Quick Coupler) Loader Model 1526L LA525 Loader Lift Height 1526L: 84 in 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) 1526L: 1,560 lb (at pivot pin) 1,082 lb (at pivot pin) Loader Breakout Force 1526L: 2,795 lb (at pivot pin) 2,373 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 7-year limited powertrain warranty Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
