▶ EngineEngine Manufacturer Mitsubishi Kubota Engine Model MVS3L2 D1005 Engine Type Four-stroke, Naturally Aspirated, Indirect Injection, Water-cooled Diesel Engine Liquid cooled, 4-cycle, diesel No. of Cylinders 3 3 Displacement 80.4 in³ 61.1 in³ Rated Engine Speed 2500 rpm 3200 rpm Engine Power (Gross) 22.9 hp 23.3 hp PTO Power 16.8 hp 19.2 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Water with pressurized radiator, reverse air-flow design Air Cleaner Not Published Dry element Fuel System Indirect Injection Direct injection Alternator 55 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump gear type Implement Flow 6.3 gpm 5.2 gpm Steering Flow 5.0 gpm 1.0 gpm Total Hydraulic Flow 11.2 gpm 6.2 gpm Overall Hydraulic Pump Flow 11.2 gpm 6.2 gpm Hydraulic System Type Open center, full-live hydraulic with position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 standard (2-valve rear remote coupler optional) No. of Optional Remote Valves 1 or 2 (single or dual) 2 (optional; ISO 7241-1 series A or B) ▶ Fluid CapacityFuel Tank Capacity 5.8 gal 6.6 gal Coolant Capacity Not Published 3.5 qt Crankcase Capacity Not Published 4.2 qt Transmission / Hydraulic System Capacity Not Published 3.0 gal Front Axle Fluid Capacity Not Published 3.8 qt ▶ PTO & HitchPTO Type Live Live independent PTO (with hydraulic clutch) PTO Rear 540 rpm @ 2376 rpm STD (540 rpm) Mid-PTO Availability Available; 2500 @ 2500 STD (2500 rpm) Category, 3-Point Hitch CAT I with Telescoping stabilizers SAE Category I Optional Hitch Lift Capacity Not Published 1,213 lb Hitch Lift Capacity (at 24”) 1760 lb 680 lb Lift Control Type Position Control Quarter-inching valve ▶ Transmission & DrivetrainTransmission Type HST Hydrostatic transmission No. of Speeds Infinite / 3 Ranges 2 Range (Low-High) Max Travel Speed (Forward) 11.2 mph 8.4 mph Max Travel Speed (Reverse) Not Published 6.5 mph Clutch Not Published Dry type single plate - Main clutch 9.45 in. Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Hydrostatic Power Steering Integral power steering Brakes Two Pedal Mechanical, wet disc type Seat Suspension & Adjustability Not Published High-back deluxe seat with armrests; fore/aft slide and backrest tilt adjustment Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating 2425 lb Not Published Drawbar Capacity Not Published Max. drawbar load @ hitch: 550 lb. ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 112.7 in 95.5 in (without 3-point hitch) Overall Width 54.4 in 45.1 in Wheelbase 61.4 in 55.1 in Ground Clearance 13.4 in 6.5 in (minimum; 8.9 in at front axle) Min. Turn Radius without Brakes 8.2 ft 7.5 ft Height to Top of ROPS 93.6 in 83.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.4 in Not Published ▶ WeightTractor Weight (Base) 2101 lb (open station); 2607 lb (cab) 1521 lb Weight with ROPS and Loader 2557 lb Not Published Weight with Cab and Loader 3063 lb Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 18X8.5-10 R1 Agricultural - Rear Not Published 26X12-12 R3 Turf - Front 8.5x14 18X8.5-10 R3 Turf - Rear 13.5-16 26X12-12 R4 Industrial - Front 8.5x14 18X8.5-10 R4 Industrial - Rear 12.4-16 26X12-12 ▶ Loader & AttachmentsQuick Attach Loader System L21: Skid-steer couplers for superfast hookups Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) Loader Model L21 (55 in bucket) LA344S (standard, quick attach); LA344 (pin-on option) Loader Lift Height L21: 77 in 71.0 in Loader Lift Capacity (Full Height) L21: 1,477 lb 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) Loader Breakout Force L21: 2,160 lb 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
