▶ EngineEngine Manufacturer Mahindra Kubota Engine Model Not Published F (2WD gear), DT (4WD gear): D1803-CR-E4-LB3; HST (4WD): D1803-CR-E4-LB4 Engine Type Four stroke, naturally aspirated, common rail, direct injection, water-cooled diesel Liquid-cooled, 3-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection No. of Cylinders 4 3 Displacement 167 in³ 111.4 in³ Rated Engine Speed 2400 rpm 2700 rpm Engine Power (Gross) 37.4 hp 37.5 hp PTO Power 31 hp F (2WD gear), DT (4WD gear): 32.1 hp; HST (4WD): 30.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled, water with pressurized radiator Air Cleaner Not Published Dry paper single element Fuel System Common rail direct injection (mCRD) Common rail (CRS) direct injection, electronic fuel injection Alternator 45 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump, gear type Implement Flow 7.6 gpm 6.3 gpm Steering Flow 4.1 gpm 3.8 gpm Total Hydraulic Flow 11.7 gpm (7.6 + 4.1, computed) 10.1 gpm Overall Hydraulic Pump Flow Not Published 10.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 or 2 Up to 3 (self canceling detent valve or float detent valve options) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 11.1 gal Coolant Capacity Not Published 6.3 qt Crankcase Capacity Not Published 7.1 qt Transmission / Hydraulic System Capacity Not Published F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal Front Axle Fluid Capacity Not Published 4.8 qt ▶ PTO & HitchPTO Type Independent Live independent PTO with hydraulic clutch PTO Rear 540 rpm @ 2400 rpm 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch CAT I with check chains (2538 HST); CAT I with telescoping stabilizers and flex link ends (2538 HST Cab) Category I Hitch Lift Capacity 2646 lb 1998 lb Hitch Lift Capacity (at 24”) Not Published 1433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST, 3 range F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range No. of Speeds Infinite, 3 ranges F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) Not Published F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) Not Published F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Clutch Multiple wet disc F (2WD gear), DT (4WD gear): Dry type dual stage; HST (4WD): Dry type single stage Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (factory certified) with retractable seat belt Steering Hydrostatic power steering, tilt Integral power steering Brakes Wet disc Mechanical wet disc type, pedals can be locked together Seat Suspension & Adjustability Adjustable suspension seat Not Published Front Axle Type Not Published F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published 2865 lb (at 41.3 in tread, 2WD and 4WD models) Drawbar Capacity Not Published 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119.3 in (2538 HST); 121.2 in (2538 HST Cab) F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in Overall Width 59.8 in 55.1 in Wheelbase Not Published 63.3 in Ground Clearance Not Published F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in Min. Turn Radius without Brakes 7.87 ft F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft Height to Top of ROPS 94.4 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.5 in Not Published ▶ WeightTractor Weight (Base) 3130 lb (2538 HST); 3351 lb (2538 HST Cab) F (2WD gear): 2590 lb; DT (4WD gear): 2767 lb; HST (4WD): 2778 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural - Front 7-16 F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front Not Published F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front 10-16.5 27x8.5-15 (4WD) R4 Industrial - Rear 43x16-20 15-19.5 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA525: 2-Lever Quick Coupler, no tools required to attach and detach loader Loader Model 2538L LA525 Loader Lift Height 2538L: 101.4 in LA525: 94.3 in Loader Lift Capacity (Full Height) 2538L: 1,634 lb LA525: 1131 lb Loader Breakout Force 2538L: 2,696 lb LA525: 2462 lbf ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 24 months or 1500 hours (general)
