▶ EngineEngine Manufacturer Mahindra LS Mtron Engine Model Not Published L3C19-T4 Engine Type Naturally aspirated direct injection diesel 3-cylinder, turbocharged diesel, Tier 4 B/Final No. of Cylinders 4 3 Displacement 166.7 in³ 116 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 35 hp 32 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Pressurized liquid cooling with recirculating bypass Air Cleaner Not Published Not Published Fuel System Direct injection High pressure common rail Alternator 45 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.5 gpm 5.3 gpm Total Hydraulic Flow 12.7 gpm (8.2 + 4.5, computed) 13.5 gpm (8.2 + 5.3, computed) (8.2 + 4.2, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 7.4 gal Coolant Capacity Not Published 7.5 qt Crankcase Capacity Not Published 5.8 qt Transmission / Hydraulic System Capacity Not Published 8.5 gal Front Axle Fluid Capacity Not Published 6.9 qt ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm @ 2650 rpm 540 rpm Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch CAT I with check chains Category I Hitch Lift Capacity 2646 lb 1,808 lb Hitch Lift Capacity (at 24”) Not Published 1,433 lb Lift Control Type Position control Mechanical Draft Control (MDC) ▶ Transmission & DrivetrainTransmission Type Synchro shuttle with partial synchromesh 3-range hydrostatic (optional) No. of Speeds 12F/12R infinite, 3 ranges Max Travel Speed (Forward) Not Published 14.8 mph Max Travel Speed (Reverse) Not Published 14.96 mph Clutch Single plate, dry Dry clutch Differential Lock & Limited Slip Options Not Published Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Power steering Brakes Wet disc Wet disc, mechanical actuation Seat Suspension & Adjustability Adjustable suspension seat Adjustable suspension seat Front Axle Type Not Published Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119.3 in 145.2 in Overall Width 59.8 in 66.5 in Wheelbase Not Published 67.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 7.87 ft 123 in Height to Top of ROPS 94.4 in 87.6 in Height to Top of ROPS (folded) Not Published 68.2 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3285 lb 3,067 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial (turf N/A) R1 agricultural, R3 turf, or R4 industrial (R4 standard) R1 Agricultural - Front 8.3x16 7x14 R1 Agricultural - Rear 12.4x24 11.2x24 R3 Turf - Front Not Published 25x8.50-14 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front 10-16.5 25x8.50-14 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 2540L L340A Loader Lift Height 2540L: 101.9 in 98.4 in Loader Lift Capacity (Full Height) 2540L: 2,041 lb 1,250 lb Loader Breakout Force 2540L: 3,430 lb 1913 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 6-year extended warranty: 2 years bumper-to-bumper plus 4 additional years of powertrain protection
