▶ EngineEngine Manufacturer Mahindra Not Published Engine Model Not Published 3H-TH4D Engine Type Naturally aspirated direct injection diesel 3-cylinder, common-rail, liquid-cooled diesel No. of Cylinders 4 3 Displacement 166.7 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 39.4 hp 39.6 hp PTO Power 35 hp 29.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Not Published Fuel System Direct injection Common rail direct injection (CRDI) Alternator 45 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 8.2 gpm Not Published Steering Flow 4.5 gpm Not Published Total Hydraulic Flow 12.7 gpm (8.2 + 4.5, computed) 16.49 gpm Overall Hydraulic Pump Flow Not Published 16.49 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 (2 port) No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 12.7 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2650 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch CAT I with check chains Category I Hitch Lift Capacity 2,646 lb Not Published Hitch Lift Capacity (at 24”) Not Published 2,716 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type Synchro shuttle with partial synchromesh Hydrostatic (HST) No. of Speeds 12F/12R 3 range (hydrostatic) Max Travel Speed (Forward) Not Published 18.5 mph Max Travel Speed (Reverse) Not Published 12.9 mph Clutch Single plate, dry Not Published Differential Lock & Limited Slip Options Not Published Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Adjustable suspension seat Deluxe adjustable suspension seat Front Axle Type Not Published Mechanical 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 59.8 in 62.8 in Wheelbase Not Published 71.3 in Ground Clearance Not Published 14.5 in Min. Turn Radius without Brakes 7.87 ft 8.63 ft (with brake applied) Height to Top of ROPS 94.4 in 96.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 93 in Overall Length 119.3 in 125.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,285 lb (operating weight) DK4210SE HST: 3,523 lb; DK4210SE HST Cab: 4,043 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial (turf N/A) R1 Agricultural: 8-16 front, 13.6-24 rear; R3 Turf: 29-12.5-15 front, 21.5L-16.1 rear; R4 Industrial: 10-16.5 front, 14.9-24 rear R1 Agricultural - Front 8.3x16 8-16 R1 Agricultural - Rear 12.4x24 13.6-24 R3 Turf - Front Not Published 29-12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 43x16-20 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach (QA) bucket, 66 in or 72 in Loader Model 2540L KL5520 (ROPS); KL5521 (Cab) Loader Lift Height 2540L: 101.9 in KL5520: 105.7 in (to pivot pin); KL5521: 105.7 in (to pivot pin) Loader Lift Capacity (Full Height) 2540L: 2,041 lb (at pivot pin) KL5520: 2,474 lb (at pivot pins); KL5521: 2,474 lb (at pivot pins) Loader Breakout Force 2540L: 3,430 lb (at pivot pin) KL5520: 3,895 lb (at pivot pins); KL5521: 3,895 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
