▶ EngineEngine Manufacturer Mahindra LS Engine Model Not Published L3C19-T Engine Type Naturally aspirated direct injection diesel 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 4 3 Displacement 166.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 35 hp 34 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Direct injection CRDI (Delphi common rail direct injection) Alternator 45 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, engine driven Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.5 gpm 5.5 gpm Total Hydraulic Flow 12.7 gpm (8.2 + 4.5, computed) 13.7 gpm Overall Hydraulic Pump Flow Not Published 13.7 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Not Published 1 or 2 pairs (optional) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 7.4 gal Coolant Capacity Not Published 1.9 gal Crankcase Capacity Not Published 1.5 gal Transmission / Hydraulic System Capacity Not Published 8.5 gal Front Axle Fluid Capacity Not Published 1.7 gal ▶ PTO & HitchPTO Type Independent Independent (wet disc clutch) PTO Rear 540 rpm @ 2650 rpm Standard (540 rpm) Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch CAT I with check chains Category I Hitch Lift Capacity 2646 lb 1,808 lb Hitch Lift Capacity (at 24”) Not Published 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle with partial synchromesh Synchro Shuttle No. of Speeds 12F/12R F12 x R12 Max Travel Speed (Forward) Not Published 14.33 mph Max Travel Speed (Reverse) Not Published 13.63 mph Clutch Single plate, dry Dry single clutch Differential Lock & Limited Slip Options Not Published Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Adjustable suspension seat Not Published Front Axle Type Not Published Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119.3 in 121 in Overall Width 59.8 in 54 in (R1); 66 in (R4) Wheelbase Not Published 69 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 7.87 ft 10.79 ft (left); 11.02 ft (right) Height to Top of ROPS 94.4 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3285 lb 2,881 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial (turf N/A) R1 agricultural, R4 industrial or R3 turf at no extra cost R1 Agricultural - Front 8.3x16 7-14 R1 Agricultural - Rear 12.4x24 11.2-24 R3 Turf - Front Not Published 25x8.50-14 R3 Turf - Rear Not Published 41x14-20 R4 Industrial - Front 10-16.5 25x8.50-14 R4 Industrial - Rear 43x16-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 2540L LL3302 Loader Lift Height 2540L: 101.9 in LL3302: 94 in Loader Lift Capacity (Full Height) 2540L: 2,041 lb LL3302: 2,153 lb (at pivot pin, full height) Loader Breakout Force 2540L: 3,430 lb LL3302: 3,579 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 6-year limited warranty
