▶ EngineEngine Manufacturer Mahindra LS Engine Model Not Published L3C19-T4 Engine Type Naturally aspirated direct injection diesel 4-stroke, vertical, water cooling, CRDI No. of Cylinders 4 3 Displacement 166.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 35 hp 34.4 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dry Fuel System Direct injection Delphi CRDI (Common Rail Direct Injection) Alternator 45 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump type, engine drive Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.5 gpm 4.1 gpm (mechanical); 5.5 gpm (HST) Total Hydraulic Flow 12.7 gpm (8.2 + 4.5, computed) 12.3 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 10.6 gal (roll-bar); 12.4 gal (cabin) Coolant Capacity Not Published 2.3 gal Crankcase Capacity Not Published 1.6 gal Transmission / Hydraulic System Capacity Not Published 11.4 gal Front Axle Fluid Capacity Not Published 2.1 gal ▶ PTO & HitchPTO Type Independent Independent PTO with wet disk clutch PTO Rear 540 rpm @ 2650 rpm 540 (standard); 540 / 750 / 1,000 (optional 3-speed) Mid-PTO Availability Not Published Yes, 2000 rpm mid-PTO Category, 3-Point Hitch CAT I with check chains Category I Hitch Lift Capacity 2646 lb 2,756 lb Hitch Lift Capacity (at 24”) Not Published 2,469 lb Lift Control Type Position control Position and draft control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle with partial synchromesh Synchro-shuttle (mechanical) No. of Speeds 12F/12R F16 x R16 (F32 x R16 with creeper, optional) Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.3 mph Clutch Single plate, dry Dry single clutch (mechanical only) Differential Lock & Limited Slip Options Not Published Mechanical pedal type differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Hydrostatic Brakes Wet disc Wet disc Seat Suspension & Adjustability Adjustable suspension seat Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119.3 in 133 in Overall Width 59.8 in 62.5 in Wheelbase Not Published 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 7.87 ft 9.5 ft (with brake applied) Height to Top of ROPS 94.4 in 93 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 92 in ▶ WeightTractor Weight (Base) 3285 lb Roll-bar: 3,770 lb; Cabin: 4,210 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial (turf N/A) Ag 9.5-16 / 13.6-24; Turf 28x8.5-15 / 41x14-20; Industrial 12-16.5 / 17.5L-24 R1 Agricultural - Front 8.3x16 9.5-16 (6PR) R1 Agricultural - Rear 12.4x24 13.6-24 (8PR) R3 Turf - Front Not Published 28x8.5-15 R3 Turf - Rear Not Published 41x14-20 R4 Industrial - Front 10-16.5 12-16.5 R4 Industrial - Rear 43x16-20 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 2540L LL4104 Loader Lift Height 2540L: 101.9 in LL4104: 96.3 in Loader Lift Capacity (Full Height) 2540L: 2,041 lb LL4104: 2,713 lb Loader Breakout Force 2540L: 3,430 lb LL4104: 3,802 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty
