▶ EngineEngine Manufacturer Mahindra Yanmar Engine Model Not Published 3TNV86CHT-MJTV Engine Type Naturally aspirated direct-injection diesel Diesel No. of Cylinders 4 3 Displacement 166.7 in³ 95.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 44 hp 44.7 hp PTO Power 39 hp 36.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid Air Cleaner Not Published Dry type with safety element Fuel System Direct injection Not Published Alternator OOS: 45 A, 12 V; Cab: 90 A, 12 V 75 A, 12 V ▶ HydraulicsPump Type Not Published Implement/steering pump: dual gear pump; hydrostatic pump: PV axial-piston pump Implement Flow 8.2 gpm 9.1 gpm Steering Flow OOS: 4.1 gpm; Cab: 4.5 gpm 6.2 gpm Total Hydraulic Flow Not Published 15.3 gpm Overall Hydraulic Pump Flow Not Published 15.3 gpm Hydraulic System Type Open Center with position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 spool optional Not Published ▶ Fluid CapacityFuel Tank Capacity 9.0 gal Open station (OOS): 13.5 gal; Cab: 11.8 gal Coolant Capacity Not Published Open station (OOS): 1.4 gal; Cab: 1.9 gal Crankcase Capacity Not Published 1.5 gal Transmission / Hydraulic System Capacity Not Published 6.8 gal Front Axle Fluid Capacity Not Published 1.3 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2650 rpm 540 rpm Mid-PTO Availability Not Published Optional (2100 rpm) Category, 3-Point Hitch CAT I with check chains Limited Category I Hitch Lift Capacity 2,646 lb 2,530 lb at hitch ball Hitch Lift Capacity (at 24”) Not Published 2,200 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle with partial synchromesh 3-range hydrostatic (eHydro) No. of Speeds 12F/12R Infinite / 3 range Max Travel Speed (Forward) Not Published 18.50 mph Max Travel Speed (Reverse) Not Published 18.50 mph Clutch Single plate, dry Not Published Differential Lock & Limited Slip Options Not Published Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Hydrostatic power steering Brakes Wet disc Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Mechanical front wheel drive (MFWD) Front Axle Rating Not Published 3,196 lb Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 63.2 in 69.1 in Wheelbase Not Published 68.0 in Ground Clearance Not Published 12.2 in Min. Turn Radius without Brakes 7.87 ft 8.8 ft (2.68 m, MFWD off) Height to Top of ROPS 94.4 in 93.3 in Height to Top of ROPS (folded) Not Published 72.0 in Height to Top of Cab Model 94.4 in 85.0 in Overall Length 119.3 in 120.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,285 lb (2545 Shuttle, operating weight); 3,506 lb (2545 Shuttle Cab, operating weight) 2,900 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 8.3x16 7-14 R1 Agricultural - Rear 12.4x24 11.2-24 R3 Turf - Front Not Published 27X8.50-15 R3 Turf - Rear Not Published 41X14-20 R4 Industrial - Front Not Published 25X8.5-14 or 27X8.5-15 R4 Industrial - Rear Not Published 15-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Tool-free attach-and-park mounting Loader Model 2545L (open station); 2545CL (cab) 300R; 320R Loader Lift Height 2545L: 101.9 in; 2545CL: 101.9 in 300R: 90 in; 320R: 102 in Loader Lift Capacity (Full Height) 2545L: 2,041 lb; 2545CL: 2,041 lb 300R: 1,360 lb; 320R: 1,598 lb (at pivot pin) Loader Breakout Force 2545L: 3,430 lb; 2545CL: 3,430 lb 300R: 2,855 lbf; 320R: 3,327 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
