▶ EngineEngine Manufacturer Mahindra KIOTI (Daedong) Engine Model Not Published 3HT-TH4C Engine Type Four-stroke, direct-injection, turbo-charged and intercooled diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 161.5 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 44 hp 44.9 hp PTO Power 39 hp 33.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry element Fuel System Direct injection Not Published Alternator 90 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 8.2 gpm 9.62 gpm Steering Flow 4.5 gpm 6.87 gpm Total Hydraulic Flow Not Published 16.5 gpm Overall Hydraulic Pump Flow Not Published 16.5 gpm Hydraulic System Type Open Center with position control Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves 1 spool optional Not Published ▶ Fluid CapacityFuel Tank Capacity 16 gal 12.7 gal Coolant Capacity Not Published 2.1 gal Crankcase Capacity Not Published 1.95 gal Transmission / Hydraulic System Capacity Not Published 11.4 gal Front Axle Fluid Capacity Not Published 1.48 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2650 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch CAT I with telescoping stabilizers & flex link ends Category I Hitch Lift Capacity Not Published 2,998 lb Hitch Lift Capacity (at 24”) Not Published 2,716 lb Lift Control Type Not Published Position ▶ Transmission & DrivetrainTransmission Type Synchro shuttle with partial synchromesh Hydrostatic (HST) No. of Speeds 12F/12R 3 ranges (hydrostatic, infinite speeds) Max Travel Speed (Forward) Not Published 18.45 mph Max Travel Speed (Reverse) Not Published 12.92 mph Clutch Single plate, dry None (hydrostatic transmission) Differential Lock & Limited Slip Options Not Published Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Hydrostatic power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Not Published Deluxe suspension seat Front Axle Type Not Published Mechanical 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119.3 in 125.5 in Overall Width 63.2 in 62.8 in Wheelbase Not Published 71.3 in Ground Clearance Not Published 14.5 in Min. Turn Radius without Brakes 11 ft 102.8 in (with brake applied) Height to Top of ROPS 94.4 in 96.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 94.4 in 93.0 in ▶ WeightTractor Weight (Base) OS: 3506 lb; Cab: not published 3,523 lb (DK4720SEH); 4,043 lb (DK4720SEH CAB) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural - Front 8.3x16 8-16 R1 Agricultural - Rear 12.4x24 13.6-24 R3 Turf - Front Not Published 29-12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach (QA) bucket, 66 in or 72 in Loader Model 2545L (open station); 2545CL (cab) KL5520; KL5521 (Cab models) Loader Lift Height 672.3 gal, 2545CL: 101.9 in KL5520: 107.7 in; KL5521: 107.7 in Loader Lift Capacity (Full Height) 672.3 gal, 2545CL: 2,041 lb KL5520: 2,474 lb; KL5521: 2,474 lb Loader Breakout Force 672.3 gal, 2545CL: 3,430 lb KL5520: 3,895 lb; KL5521: 3,895 lb ▶ WarrantyWarranty Length & Coverage Not Published Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
