▶ EngineEngine Manufacturer Mahindra Mahindra Engine Model Not Published DH45 Engine Type Naturally aspirated direct-injection diesel Four-stroke, naturally aspirated, direct injection, water-cooled diesel No. of Cylinders 4 4 Displacement 166.7 in³ 166.2 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 44 hp 45 hp PTO Power 39 hp 38 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Not Published Not Published Fuel System Direct injection Direct injection Alternator OOS: 45 A, 12 V; Cab: 90 A, 12 V 55 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 8.2 gpm 8.71 gpm Steering Flow OOS: 4.1 gpm; Cab: 4.5 gpm 4.62 gpm Total Hydraulic Flow Not Published 13.3 gpm Overall Hydraulic Pump Flow Not Published 13.3 gpm Hydraulic System Type Open Center with position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published One No. of Optional Remote Valves 1 spool optional One (optional second rear valve) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 17.1 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2650 rpm 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT I with check chains CAT I & II with telescopic stabilizers & flex links Hitch Lift Capacity 2,646 lb Not Published Hitch Lift Capacity (at 24”) Not Published 3,748 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle with partial synchromesh Full synchromesh with forward/reverse synchro shuttle and constant-mesh range No. of Speeds 12F/12R 12F / 12R Max Travel Speed (Forward) Not Published 17.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Single plate, dry Dual dry with cerametallic lining Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Power steering with tilt steering wheel Brakes Wet disc Fully-enclosed, 7-in diameter, dry disc Seat Suspension & Adjustability Not Published Adjustable seat with contoured cushions, armrests and a soft-coil suspension Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 63.2 in 74.8 in Wheelbase Not Published 77.9 in Ground Clearance Not Published 15.2 in Min. Turn Radius without Brakes 7.87 ft 10.8 ft (3.29 m) Height to Top of ROPS 94.4 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 94.4 in Not Published Overall Length 119.3 in 136.6 in ▶ WeightTractor Weight (Base) 3,285 lb (2545 Shuttle, operating weight); 3,506 lb (2545 Shuttle Cab, operating weight) 5,390 lb Weight with ROPS and Loader Not Published 6,690 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural or R4 Industrial R1 Agricultural - Front 8.3x16 9.5 x 20 R1 Agricultural - Rear 12.4x24 14.9 x 28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 10.5/80 x 18 R4 Industrial - Rear Not Published 16.9 x 24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer style quick-attach coupler Loader Model 2545L (open station); 2545CL (cab) 5155-4L (front loader); 65B (rear backhoe) Loader Lift Height 2545L: 101.9 in; 2545CL: 101.9 in 122 in Loader Lift Capacity (Full Height) 2545L: 2,041 lb; 2545CL: 2,041 lb 3,100 lb Loader Breakout Force 2545L: 3,430 lb; 2545CL: 3,430 lb 5,200 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year limited powertrain warranty
