▶ EngineEngine Manufacturer Mahindra Kubota Engine Model Not Published V3307-DI Engine Type Turbocharged and intercooled, direct injection diesel 4-cylinder inline, direct injected diesel No. of Cylinders 3 4 Displacement 161.5 in³ 203 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 55 hp Not Published PTO Power 43.9 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published 8 in dry, dual element Fuel System Turbocharged and intercooled, direct injection Direct injection Alternator 90 A, 12 V ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.5 gpm (2555 Shuttle); 9.7 gpm (2555 HST); 9.5 gpm (2555 Shuttle Cab); 9.7 gpm (2555 HST Cab) 11.0 gpm Steering Flow 5 gpm (2555 HST); 5 gpm (2555 Shuttle Cab); 5 gpm (2555 HST Cab) 6.1 gpm Total Hydraulic Flow 14.5 gpm (9.5 + 5, computed) (2555 Shuttle); 14.7 gpm (9.7 + 5, computed) (2555 HST) 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow Not Published 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 (2nd spool) 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 16 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity Not Published 8.5 qt Crankcase Capacity Not Published 11.6 qt Transmission / Hydraulic System Capacity Not Published 59.2 qt Front Axle Fluid Capacity Not Published Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side ▶ PTO & HitchPTO Type Independent Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm @ 2300 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT I with telescoping stabilizers and flex link ends Category I and II Hitch Lift Capacity 3,314 lb 4,189 lb Hitch Lift Capacity (at 24”) Not Published 3,307 lb Lift Control Type Position control Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle with partial synchromesh (2555 Shuttle); HST, 3 ranges (2555 HST); synchro shuttle with partial synchromesh (2555 Shuttle Cab); HST, 3 ranges (2555 HST Cab) Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 12F/12R (2555 Shuttle); Infinite, 3 ranges (2555 HST) 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) Not Published 17.8 mph Max Travel Speed (Reverse) Not Published 18.0 mph Clutch 2555 Shuttle, 2555 Shuttle Cab: single-plate dry; 2555 HST, 2555 HST Cab: n/a Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Not Published Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic power steering, tilt Hydrostatic power steering Brakes Wet disc Multiple wet disc, mechanical Seat Suspension & Adjustability Adjustable suspension seat Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Not Published 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 71.1 in (2555 Shuttle); 71.1 in (2555 HST); 71.5 in (2555 Shuttle Cab); 71.5 in (2555 HST Cab) 73.2 in Wheelbase Not Published 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes 11 ft 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS 102 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 98 in 99.8 in Overall Length 135.4 in 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 4,056 lb (2555 Shuttle, operating weight); 4,056 lb (2555 HST, operating weight); 4,299 lb (2555 Shuttle Cab, operating weight); 4,299 lb (2555 HST Cab, operating weight) 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial (turf N/A) Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 9.5x16 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear 14.9x24 16.9-28 R3 Turf - Front N/A 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear N/A 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front 12x16.5 12.5/80-18 (4WD) R4 Industrial - Rear 16.9x24 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA1153: two-lever quick coupler Loader Model 2555L (2555 Shuttle, 2555 HST); 2555CL (2555 Shuttle Cab, 2555 HST Cab) LA1153 Loader Lift Height 2555L: 115.4 in; 2555CL: 115.4 in LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) 2555L: 3,122 lb (at pivot pin) Not Published Loader Breakout Force 2555L: 5,225 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage 7-year limited powertrain warranty Not Published
