▶ EngineEngine Manufacturer Mahindra Yanmar Engine Model Not Published 4TNV86CHT-MJT Engine Type Four stroke, direct injection, turbo-charged and intercooled diesel Turbocharged 4-cylinder Diesel No. of Cylinders 3 4 Displacement 161.5 in³ 127.6 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 65 hp 65.9 hp PTO Power 50 hp 58 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dual element (dry type with safety element) Fuel System Direct injection, turbocharged and intercooled (mCRD common rail) High-pressure common rail direct injection Alternator 90 A, 12 V 75 A, 12 V ▶ HydraulicsPump Type Not Published Dual Independent Implement Flow 11 gpm 10.2 gpm Steering Flow 5.4 gpm 5.7 gpm Total Hydraulic Flow 16.4 gpm (11 + 5.4, computed) 15.9 gpm Overall Hydraulic Pump Flow Not Published 15.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Not Published 3rd, 4th, and 5th optional (up to 5 total) ▶ Fluid CapacityFuel Tank Capacity 16 gal 15.0 gal Coolant Capacity Not Published 6.8 qt Crankcase Capacity Not Published 5.6 qt (with filter) Transmission / Hydraulic System Capacity Not Published 12.5 gal Front Axle Fluid Capacity Not Published 5.3 qt ▶ PTO & HitchPTO Type Independent Independent (electrohydraulic) PTO Rear 540 rpm @ 2300 rpm 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch CAT II with telescoping stabilizers and flex link ends Category I Hitch Lift Capacity 3527 lb 3,130 lb Hitch Lift Capacity (at 24”) Not Published 2,500 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle with partial synchromesh Standard: 12F/12R PowrReverser; Optional: eHydro (3-range hydrostatic) No. of Speeds 12F/12R 12F/12R Max Travel Speed (Forward) Not Published 18.6 mph Max Travel Speed (Reverse) Not Published 18.6 mph Clutch Single plate, dry Wet disc (PowrReverser); not applicable on eHydro Differential Lock & Limited Slip Options Not Published Differential lock: standard, rear, mechanical ▶ Chassis, Steering & ControlsFrame Type Not Published ROPS - Foldable Steering Hydrostatic power steering, tilt Power steering (hydrostatic) Brakes Wet disc Wet disc Seat Suspension & Adjustability Adjustable suspension seat Optional mechanical suspension seat; adjustable weight 52-275.6 lb (115-275 lb); fore/aft adjustment; flips forward Front Axle Type Not Published Mechanical front wheel drive (MFWD) - Standard Front Axle Rating Not Published (Continuous) 3307 lb Drawbar Capacity Not Published Max vertical load 1103 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 142 in 130.6 in Overall Width 71.5 in 78.2 in Wheelbase Not Published 73.0 in Ground Clearance Not Published Front axle: 13.8 in Min. Turn Radius without Brakes 12.5 ft 17.1 ft (5.2 m) Height to Top of ROPS Not Published 100.2 in Height to Top of ROPS (folded) Not Published 69.5 in Height to Top of Cab Model 99.2 in Not Published ▶ WeightTractor Weight (Base) 5070 lb (2565 Shuttle Cab) 3,770 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Turf R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5x20 8.00-16 (6PR) R1 Agricultural - Rear 14.9x28 13.6-28 R3 Turf - Front LSW305-521 27X10.50-15 R3 Turf - Rear LSW570-648 44X18.00-20 (4PR) R4 Industrial - Front 10.5/80x18 260/70D16.5 R4 Industrial - Rear 18.4x24 420/85D24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) Loader Model 2565CL D170 Loader Lift Height 2565CL: 115.4 in 112.1 in Loader Lift Capacity (Full Height) 2565CL: 3,122 lb 2,391 lb (at pivot, NSL) Loader Breakout Force 2565CL: 5,225 lb At pivot: 3,853 lbf; @ 19.7 in ahead of pivot: 2,902 lbf ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
