▶ EngineEngine Manufacturer Mahindra John Deere Engine Model Not Published PowerTech 3029H Engine Type Four stroke, direct injection, turbo-charged and intercooled diesel Diesel, turbocharged, liquid-cooled No. of Cylinders 3 3 Displacement 161.5 in³ 179 in³ Rated Engine Speed 2300 rpm 2100 rpm Engine Power (Gross) 65 hp 65 hp PTO Power 50 hp 48.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Two paper elements Fuel System Direct injection, turbocharged and intercooled (mCRD common rail) Not Published Alternator 90 A, 12 V 40 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11 gpm 11.4 gpm Steering Flow 5.4 gpm 6.8 gpm Total Hydraulic Flow 16.4 gpm (11 + 5.4, computed) 18.2 gpm Overall Hydraulic Pump Flow Not Published 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 16 gal OOS: 18.0 gal; Cab: 21.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published 9 qt Transmission / Hydraulic System Capacity Not Published 2WD: 10 gal; 4WD: 10.3 gal Front Axle Fluid Capacity Not Published 4.8 qt ▶ PTO & HitchPTO Type Independent OOS: Independent, mechanical actuation; Cab: Independent, mechanical or electrohydraulic actuation PTO Rear 540 rpm @ 2300 rpm 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT II with telescoping stabilizers and flex link ends Category II, convertible to I Hitch Lift Capacity 3527 lb Not Published Hitch Lift Capacity (at 24”) Not Published 3,192 lb Lift Control Type Position and draft control Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type Synchro shuttle with partial synchromesh SyncShuttle (standard); PowrReverser (optional) No. of Speeds 12F/12R 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Single plate, dry Dry (SyncShuttle); Dry/Wet with 12F/12R PowrReverser Differential Lock & Limited Slip Options Not Published Rear diff lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Power steering Brakes Wet disc Hydraulic wet disc brakes Seat Suspension & Adjustability Adjustable suspension seat Not Published Front Axle Type Not Published 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 142 in 137.8 in Overall Width 71.5 in 57.3 in Wheelbase Not Published 80.7 in Ground Clearance Not Published 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 12.5 ft 138 in Height to Top of ROPS Not Published 98.4 in Height to Top of ROPS (folded) Not Published 78.5 in Height to Top of Cab Model 99.2 in 95.6 in ▶ WeightTractor Weight (Base) 5070 lb (2565 Shuttle Cab) 2WD: 4,634 lb; MFWD: 5,621 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 7,165 lb ▶ Tire OptionsTire Size & Options Ag, Industrial, Turf Not Published R1 Agricultural - Front 9.5x20 2WD: 7.5-16; MFWD: 9.5-24 R1 Agricultural - Rear 14.9x28 16.9-28 R3 Turf - Front LSW305-521 9.5-16 (4WD) R3 Turf - Rear LSW570-648 21.5L-16.1 R4 Industrial - Front 10.5/80x18 12.5-80-18 (4WD) R4 Industrial - Rear 18.4x24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published H240 (NSL or MSL) Loader Model 2565CL H240NSL Loader Lift Height 2565CL: 115.4 in 131 in Loader Lift Capacity (Full Height) 2565CL: 3,122 lb 3,671 lb Loader Breakout Force 2565CL: 5,225 lb 4,504 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
