▶ EngineEngine Manufacturer Mahindra Yanmar Engine Model CE-38 Not Published Engine Type Naturally aspirated, direct injection, liquid-cooled diesel Not Published No. of Cylinders 4 Not Published Displacement 166.7 in³ Not Published Rated Engine Speed 2400 rpm 3000 rpm Engine Power (Gross) 36.9 hp 36.9 hp PTO Power 31 hp 27.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Not Published Air Cleaner Dry dual element Not Published Fuel System Direct Injection (mCRD fuel-injected) Not Published Alternator 90 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 7.6 gpm 6.1 gpm Steering Flow 4.1 gpm 4.4 gpm Total Hydraulic Flow 11.7 gpm 10.5 gpm Overall Hydraulic Pump Flow 11.7 gpm 10.5 gpm Hydraulic System Type Open Center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 (optional) 1 or 2 ▶ Fluid CapacityFuel Tank Capacity 9 gal 9.0 gal Coolant Capacity 1.85 gal Not Published Crankcase Capacity 2.25 gal Not Published Transmission / Hydraulic System Capacity 8.5 gal Not Published Front Axle Fluid Capacity 2.166 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2400 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm @ 2500 engine rpm Not Published Category, 3-Point Hitch CAT I Category I Hitch Lift Capacity 2,646 lb 2,639 lb Hitch Lift Capacity (at 24”) Not Published 1,558 lb Lift Control Type Position Control Not Published ▶ Transmission & DrivetrainTransmission Type HST Hydrostatic No. of Speeds Infinite / 3 Ranges Not Published Max Travel Speed (Forward) 15.05 mph Not Published Max Travel Speed (Reverse) 14.38 mph Not Published Clutch Damper Not Published Differential Lock & Limited Slip Options Bevel gears with diff-lock Rear differential lock (foot pedal engagement) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Not Published Brakes Wet Disc Brake, Mechanical Dual brakes Seat Suspension & Adjustability Seat with mechanical suspension, adjustable headrest, folding armrests Not Published Front Axle Type Center pin Selectable 2WD/4WD engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 63.2 in Not Published Wheelbase 67.7 in Not Published Ground Clearance 14.5 in 12.8 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 94.4 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 119.3 in Not Published ▶ WeightTractor Weight (Base) 3,130 lb 3,020 lb Weight with ROPS and Loader 4,115 lb (3,130 + 985, computed; 696.9 gal loader shipping weight) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial Not Published R1 Agricultural - Front 7-16 6PR Not Published R1 Agricultural - Rear 11.2-24 4PR Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 43x16-20 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 2638L: quick-attach adapter included Not Published Loader Model 2638L (66 in bucket) RL505 Loader Lift Height 2638L: 101.4 in RL505: 101.5 in (at pivot pin) Loader Lift Capacity (Full Height) 2638L: 1,634 lb (at pivot pin) RL505: 2,116 lb (at pivot pin) Loader Breakout Force 2638L: 2,696 lb RL505: 3,435 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours; powertrain 10 years or 3,000 hours
