▶ EngineEngine Manufacturer Mahindra Kubota Engine Model CE-38 D1803-CR-E4-GL2 Engine Type Naturally aspirated, direct injection, liquid-cooled diesel Naturally aspirated, multi-valve, liquid-cooled diesel No. of Cylinders 4 3 Displacement 166.7 in³ 111.4 in³ Rated Engine Speed 2400 rpm 2600 rpm Engine Power (Gross) 36.9 hp 37 hp PTO Power 29.5 hp 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry dual element Dry paper, dual element Fuel System Direct Injection (mCRD fuel-injected) Electronic CRS (Common Rail System) Alternator 90 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 7.6 gpm 9.4 gpm Steering Flow 4.1 gpm 4.7 gpm Total Hydraulic Flow 11.7 gpm 14.1 gpm Overall Hydraulic Pump Flow 11.7 gpm 14.1 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None standard (up to 3 optional) No. of Optional Remote Valves 1 (optional) Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 9 gal 13.5 gal Coolant Capacity 1.85 gal 7.9 qt Crankcase Capacity 2.25 gal 7.1 qt Transmission / Hydraulic System Capacity 8.5 gal 11.1 gal Front Axle Fluid Capacity 2.17 gal 6.9 qt ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 rpm @ 2400 rpm 540 rpm @ 2476 engine rpm Mid-PTO Availability Optional, 2000 rpm @ 2500 engine rpm Optional Category, 3-Point Hitch CAT I SAE Category I Hitch Lift Capacity 2,646 lb 3,750 lb Hitch Lift Capacity (at 24”) Not Published 2,646 lb Lift Control Type Position Control Position control ▶ Transmission & DrivetrainTransmission Type HST Hydrostatic No. of Speeds Infinite / 3 Ranges 3-Range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 15.05 mph 16.5 mph Max Travel Speed (Reverse) 14.38 mph 14.9 mph Clutch Damper Not Published Differential Lock & Limited Slip Options Bevel gears with diff-lock Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet Disc Brake, Mechanical Wet disc type, mechanically activated Seat Suspension & Adjustability Seat with mechanical suspension, adjustable headrest, folding armrests Suspension seat with swivel (standard); air-suspension seat (optional) Front Axle Type Center pin 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 63.2 in 59.8 in Wheelbase 67.7 in 71.1 in Ground Clearance 14.5 in 13.5 in Min. Turn Radius without Brakes Not Published 8.9 ft (with brake applied) Height to Top of ROPS Not Published 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 94.4 in Not Published Overall Length 119.3 in 129.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,351 lb 3,483 lb (DT ROPS); 3,494 lb (GST ROPS); 3,505 lb (HST ROPS); 3,880 lb (HSTC cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 4,336 lb (3,351 + 985, computed; 2638CL loader shipping weight) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 7-16 6PR 7.0-16 R1 Agricultural - Rear 11.2-24 4PR 12.4-24 R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 41x18LL-16.1 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 43x16-20 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System 2638CL: quick-attach adapter included LA555: 2-lever mechanical quick coupler (standard); LA805: 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model 2638CL (66 in bucket) LA555 or LA805 Loader Lift Height 2638CL: 101.4 in LA555: 96.4 in; LA805: 104.7 in Loader Lift Capacity (Full Height) 2638CL: 1,634 lb LA555: 1,190 lb; LA805: 1,715 lb Loader Breakout Force 2638CL: 2,696 lb LA555: 2,030 lb; LA805: 2,549 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
