▶ EngineEngine Manufacturer Mahindra Yanmar Engine Model CE-38 3TNV88-CR Engine Type Naturally aspirated, direct injection, liquid-cooled diesel Natural aspiration No. of Cylinders 4 3 Displacement 166.7 in³ 100.2 in³ Rated Engine Speed 2400 rpm 3000 rpm Engine Power (Gross) 36.9 hp 36.9 hp PTO Power 29.5 hp 30.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry dual element Dual dry Fuel System Direct Injection (mCRD fuel-injected) Common Rail Direct Injection Alternator 90 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 7.6 gpm 6.4 gpm Steering Flow 4.1 gpm 4.6 gpm Total Hydraulic Flow 11.7 gpm 11.0 gpm Overall Hydraulic Pump Flow 11.7 gpm 11.0 gpm Hydraulic System Type Open Center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves 1 (optional) 1 ▶ Fluid CapacityFuel Tank Capacity 9 gal 9.0 gal Coolant Capacity 1.85 gal 7.4 qt Crankcase Capacity 2.25 gal 6.0 qt Transmission / Hydraulic System Capacity 8.5 gal 9.25 gal Front Axle Fluid Capacity 2.17 gal 8.7 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2400 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm @ 2500 engine rpm No mid-PTO offered Category, 3-Point Hitch CAT I Category I Hitch Lift Capacity 2,646 lb 2,646 lb Hitch Lift Capacity (at 24”) Not Published 1,764 lb Lift Control Type Position Control Position ▶ Transmission & DrivetrainTransmission Type HST 12F/12R Syncro Shuttle No. of Speeds Infinite / 3 Ranges 12 forward, 12 reverse Max Travel Speed (Forward) 15.05 mph Not Published Max Travel Speed (Reverse) 14.38 mph Not Published Clutch Damper Single plate dry clutch (8.86 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options Bevel gears with diff-lock 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Power steering Hydrostatic power steering Brakes Wet Disc Brake, Mechanical Wet disc Seat Suspension & Adjustability Seat with mechanical suspension, adjustable headrest, folding armrests Suspension seat with armrests and retractable seat belt, standard Front Axle Type Center pin Center-pivot, reverse Elliot type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 63.2 in 53.5 in Wheelbase 67.7 in Not Published Ground Clearance 14.5 in 12.8 in Min. Turn Radius without Brakes Not Published 116 in Height to Top of ROPS Not Published 94.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 94.4 in Not Published Overall Length 119.3 in 126 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,351 lb 3,020 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 4,336 lb (3,351 + 985, computed; 2638CL loader shipping weight) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt) R1 Agricultural - Front 7-16 6PR Not Published R1 Agricultural - Rear 11.2-24 4PR Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 43x16-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System 2638CL: quick-attach adapter included L102: Skid-steer compatible quick-attach Loader Model 2638CL (66 in bucket) L102 Loader Lift Height 2638CL: 101.4 in L102: 102 in Loader Lift Capacity (Full Height) 2638CL: 1,634 lb L102: 2,116 lb to full height Loader Breakout Force 2638CL: 2,696 lb L102: 3,435 lb ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 8 years or 3,000 hours, no deductible, parts and labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
