▶ EngineEngine Manufacturer Mahindra Kubota Engine Model VNEF4352 V3307-DI Engine Type Turbocharged and intercooled, direct injection diesel 4-cylinder inline, direct injected diesel No. of Cylinders 3 4 Displacement 161.5 in³ 203 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 55 hp Not Published PTO Power 44.5 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Water-cooled, forced circulation Liquid-cooled Air Cleaner Dry dual element 8 in dry, dual element Fuel System Turbocharged and intercooled, direct injection, common-rail Direct injection Alternator 90 A, 12 V ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Gear pumps: main 1.2 in³/rev, power steering 0.5 in³/rev Not Published Implement Flow 9.5 gpm (2655 Shuttle); 9.5 gpm (2655 Shuttle Cab); 9.7 gpm (2655 HST); 9.7 gpm (2655 HST Cab) 11.0 gpm Steering Flow 5 gpm 6.1 gpm Total Hydraulic Flow Not Published 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow Not Published 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 16 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity 2.35 gal (2655 HST); 2.35 gal (2655 HST Cab) 8.5 qt Crankcase Capacity 2.25 gal (2655 HST); 2.25 gal (2655 HST Cab) 11.6 qt Transmission / Hydraulic System Capacity 9.25 gal (2655 HST); 9.25 gal (2655 HST Cab) 59.2 qt Front Axle Fluid Capacity 2.64 gal (2655 HST); 2.64 gal (2655 HST Cab) Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side ▶ PTO & HitchPTO Type Independent Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm @ 2300 rpm 540 rpm Mid-PTO Availability n/a (2655 Shuttle); n/a (2655 Shuttle Cab); optional, 2000 rpm (2655 HST); optional, 2000 rpm (2655 HST Cab) Not Published Category, 3-Point Hitch CAT I Category I and II Hitch Lift Capacity 3,314 lb 4,189 lb Hitch Lift Capacity (at 24”) 2,945 lb 3,307 lb Lift Control Type Position control Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type Synchro-mesh shuttle with partial synchromesh (2655 Shuttle); synchro-mesh shuttle with partial synchromesh (2655 Shuttle Cab); HST, 3 ranges (2655 HST); HST, 3 ranges (2655 HST Cab) Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 12F/12R (2655 Shuttle); 12F/12R (2655 Shuttle Cab); infinite, 3 ranges (2655 HST); infinite, 3 ranges (2655 HST Cab) 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) 15.66 mph (2655 HST); 15.66 mph (2655 HST Cab) 17.8 mph Max Travel Speed (Reverse) 15.66 mph (2655 HST); 15.66 mph (2655 HST Cab) 18.0 mph Clutch Damper (HST) (2655 HST); Damper (HST) (2655 HST Cab) Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Rear differential lock Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Multiple wet disc, mechanical Seat Suspension & Adjustability Seat with adjustable mechanical suspension, folding armrests and retractable belt Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Center pin, MFWD (4WD) standard 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 71.1 in 73.2 in Wheelbase 74.0 in (2655 HST); 74.0 in (2655 HST Cab) 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance 13.8 in 15.4 in Min. Turn Radius without Brakes Not Published 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS 102 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102 in 99.8 in Overall Length 135 in 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 4,056 lb (2655 Shuttle); 4,299 lb (2655 Shuttle Cab); 4,056 lb (2655 HST); 4,299 lb (2655 HST Cab) 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Turf Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 9.5x16 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear 14.9x24 16.9-28 R3 Turf - Front LSW305-521 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear LSW570-648 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front 12x16.5 12.5/80-18 (4WD) R4 Industrial - Rear 16.9x24 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA1153: two-lever quick coupler Loader Model 2655L (2655 Shuttle, 2655 HST); 2655CL (2655 Shuttle Cab, 2655 HST Cab) LA1153 Loader Lift Height 2655L: 115.4 in; 2655CL: 115.4 in LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) 2655L: 3,122 lb; 2655CL: 3,122 lb Not Published Loader Breakout Force 2655L: 5,225 lb; 2655CL: 5,225 lb Not Published ▶ WarrantyWarranty Length & Coverage 7-year/3000-hour limited powertrain warranty, no deductible Not Published
