▶ EngineEngine Manufacturer Mahindra LS Mtron Engine Model VNEF4352 L3CRV-T7 Engine Type Four-stroke, direct injection, turbocharged and intercooled diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 161.5 in³ 114.7 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 55 hp 55 hp PTO Power 44.5 hp Gear: 46.7 hp; HST: 44 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled, forced circulation Liquid cooled Air Cleaner Dry dual element Replaceable primary and inner elements Fuel System Direct injection, turbocharged and intercooled (mCRD common rail) Electronically controlled common rail direct injection Alternator 90 A, 12 V ROPS: 70 A, 12 V; Cab: 85 A, 12 V ▶ HydraulicsPump Type Gear pumps: main 1.2 in³/rev, power steering 0.5 in³/rev Gear Implement Flow 9.5 gpm (2655 Shuttle); 9.5 gpm (2655 Shuttle Cab); 9.7 gpm (2655 HST); 9.7 gpm (2655 HST Cab) 8.2 gpm Steering Flow 5 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow Not Published Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow Not Published Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 16 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity 2.35 gal (2655 HST); 2.35 gal (2655 HST Cab) 2.3 gal Crankcase Capacity 2.25 gal (2655 HST); 2.25 gal (2655 HST Cab) 5.8 qt Transmission / Hydraulic System Capacity 9.25 gal (2655 HST); 9.25 gal (2655 HST Cab) 11.4 gal Front Axle Fluid Capacity 2.64 gal (2655 HST); 2.64 gal (2655 HST Cab) 2.2 gal ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm @ 2300 rpm 540 rpm Mid-PTO Availability N/A (2655 Shuttle); N/A (2655 Shuttle Cab); Optional, 2000 rpm (2655 HST); Optional, 2000 rpm (2655 HST Cab) Standard (2000 rpm) Category, 3-Point Hitch CAT I Category I Hitch Lift Capacity 3314 lb 2,756 lb Hitch Lift Capacity (at 24”) 2945 lb 2,116 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Synchro mesh shuttle with partial synchromesh (2655 Shuttle); Synchro mesh shuttle with partial synchromesh (2655 Shuttle Cab); HST, 3 ranges (2655 HST); HST, 3 ranges (2655 HST Cab) Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 12F/12R (2655 Shuttle); 12F/12R (2655 Shuttle Cab); Infinite, 3 ranges (2655 HST); Infinite, 3 ranges (2655 HST Cab) Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) 15.66 mph (2655 HST); 15.66 mph (2655 HST Cab) Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) 15.66 mph (2655 HST); 15.66 mph (2655 HST Cab) Gear: 15.3 mph; HST: 11.37 mph Clutch Damper (HST) (2655 HST); Damper (HST) (2655 HST Cab) Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Rear differential lock Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability mComfort seat with adjustable mechanical suspension, foldable armrests and retractable belt ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type Center pin, MFWD (4WD) standard Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 135 in 128.1 in Overall Width 71.1 in 69.1 in Wheelbase 74.0 in (2655 HST); 74.0 in (2655 HST Cab) 73.2 in Ground Clearance 13.8 in 15 in Min. Turn Radius without Brakes Not Published 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS 102 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102 in 94 in ▶ WeightTractor Weight (Base) 4056 lb (2655 Shuttle); 4299 lb (2655 Shuttle Cab); 4056 lb (2655 HST); 4299 lb (2655 HST Cab) ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Turf R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5x16 9.5-16 R1 Agricultural - Rear 14.9x24 13.6-24 R3 Turf - Front LSW305-521 28x8.50-15 R3 Turf - Rear LSW570-648 41x14.00-20 R4 Industrial - Front 12x16.5 12x16.5 R4 Industrial - Rear 16.9x24 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published New Holland Quick Mount loader; optional skid steer quick attach plates Loader Model 2655L (2655 Shuttle, 2655 HST); 2655CL (2655 Shuttle Cab, 2655 HST Cab) 260TLA Loader Lift Height 2655L: 115.4 in; 2655CL: 115.4 in 260TLA: 109 in Loader Lift Capacity (Full Height) 2655L: 3,122 lb; 2655CL: 3,122 lb 260TLA: 2,371 lb Loader Breakout Force 2655L: 5,225 lb; 2655CL: 5,225 lb 260TLA: 4,081 lb ▶ WarrantyWarranty Length & Coverage 7-year/3000-hour limited powertrain warranty, no deductible Boomer Guard6 limited warranty: 2 years/750 hours full coverage plus 4 more years of powertrain coverage (6 years/1,500 hours total)
