▶ EngineEngine Manufacturer Mahindra John Deere Engine Model VNEF 3029H Engine Type Turbocharged, direct injection, liquid-cooled diesel Diesel, turbocharged No. of Cylinders 3 3 Displacement 161.7 in³ 179 in³ Rated Engine Speed 2300 rpm 2100 rpm Engine Power (Gross) 60 hp 60 hp PTO Power 46.3 hp PR/TSS OOS: 48.3 hp; PR/TSS Cab: 46.3 hp; eHydro: 38.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid cooled Air Cleaner Dual dry Dry type with safety element Fuel System Direct Injection (mCRD fuel-injected) Electronically controlled, high-pressure common rail Alternator 90 A, 12 V 110 A ▶ HydraulicsPump Type Not Published Tandem gear pump (implement + steering) Implement Flow 11.8 gpm 11.4 gpm Steering Flow 4.9 gpm 6.8 gpm Total Hydraulic Flow 16.7 gpm 18.2 gpm Overall Hydraulic Pump Flow 16.7 gpm 18.2 gpm Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves 1 Spool 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 16 gal OOS: 19 gal; Cab: 21 gal Coolant Capacity 9.0 qt Not Published Crankcase Capacity 7.1 qt 9.0 qt (with filter) Transmission / Hydraulic System Capacity 9.2 gal Not Published Front Axle Fluid Capacity 10.5 qt DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2300 rpm 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability Optional Not Published Category, 3-Point Hitch CAT I with Telescoping Stabilizers & Flex Links Category II, convertible to I Hitch Lift Capacity 3,314 lb 3,968 lb Hitch Lift Capacity (at 24”) 2,945 lb 3,192 lb Lift Control Type Position Control Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type HST SyncShuttle (standard); PowrReverser (optional) No. of Speeds Infinite / 3 Ranges 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) 17.6 mph 15.5 mph (SyncShuttle) Max Travel Speed (Reverse) 17.6 mph Not Published Clutch Damper Wet traction clutch (PowrReverser) Differential Lock & Limited Slip Options Not Published Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet Disc Brake, Mechanical Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Seat with mechanical suspension, adjustable headrest, folding armrests Not Published Front Axle Type Not Published 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 138.8 in Not Published Overall Width 71.1 in Not Published Wheelbase 73.7 in 80.7 in Ground Clearance 14.5 in Not Published Min. Turn Radius without Brakes 155.5 in 137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102 in Not Published ▶ WeightTractor Weight (Base) 4,585 lb 5,445 to 6,702 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 5,855 lb (4,585 + 1,270, computed; 2660CL loader shipping weight) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial, R3 Turf Not Published R1 Agricultural - Front 9.5X16 6PR MFWD: 9.5-24; 11.2-24; 12.4-24 R1 Agricultural - Rear 14.9X24 6PR 14.9-28 R3 Turf - Front LSW305-521 Not Published R3 Turf - Rear LSW570-648 Not Published R4 Industrial - Front 12X16.5 6PR Not Published R4 Industrial - Rear 16.9X24 8PR Not Published ▶ Loader & AttachmentsQuick Attach Loader System 2660CL: quick-attach adapter included 520M or H240 Loader Model 2660CL 512 or 520M Loader Lift Height 2660CL: 115.4 in 512: 113 in; 520M: 132 in Loader Lift Capacity (Full Height) 2660CL: 3,122 lb at pivot pin to full height 512: 2,453 lb; 520M: 3,523 lb Loader Breakout Force 2660CL: 5,225 lb 512: 4,781 lb; 520M: 4,641 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
