▶ EngineEngine Manufacturer Mahindra FPT Engine Model Not Published R 753 IE4 Engine Type Four-stroke, Turbocharged, Direct Injection, Water Cooled Diesel Engine 3-cylinder, FPT turbocharged & aftercooled No. of Cylinders 3 3 Displacement 161.7 in³ 135.9 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 70 hp 70 hp PTO Power 53.8 hp 62 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Direct injection Electronic high pressure common rail Alternator 90 A, 12 V 75 A ▶ HydraulicsPump Type Not Published Engine-driven dual gear-type Implement Flow 11.8 gpm 11.9 gpm Steering Flow Not Published 5.5 gpm Total Hydraulic Flow 16.7 gpm 17.4 gpm (11.9 + 5.5, computed) Overall Hydraulic Pump Flow 16.7 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity Not Published 17.2 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2300 rpm 540 / 540E Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT II with telescoping stabilizers & flex links Category I/II Hitch Lift Capacity 3528 lb Not Published Hitch Lift Capacity (at 24”) Not Published 2,701 lb Lift Control Type Position and draft control Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type Power Shuttle 8x8 mechanical shuttle (dry clutch) No. of Speeds 12F / 12R 8F/8R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate Dry clutch Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock; MFD engagement mechanical; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Wet disc brakes Wet disc Seat Suspension & Adjustability Not Published Contoured seat, adjustable Front Axle Type Not Published 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 144.4 in 2WD: 129.5 in; MFD: 134.0 in Overall Width 71.5 in 67.5 in Wheelbase 83 in 2WD: 77.5 in; MFD: 77.7 in Ground Clearance 15.7 in Not Published Min. Turn Radius without Brakes Not Published 2WD: 135.8 in; MFD: 190.9 in Height to Top of ROPS Not Published 2WD: 92.7 in; MFD: 97.4 in Height to Top of ROPS (folded) Not Published 77 in Height to Top of Cab Model 102 in Not Published ▶ WeightTractor Weight (Base) 5390 lb 2WD: 4,442 lb; MFD: 5,060 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial R1 (bar tread) 2WD or MFD; R4 (industrial tread) MFD R1 Agricultural - Front 9.5 x 20 2WD: 7.5x16; MFD: 8.3x24 R1 Agricultural - Rear 14.9 x 28 13.6x28 R3 Turf - Front LSW305-521 Not Published R3 Turf - Rear LSW570-648 Not Published R4 Industrial - Front 10.5/80 x 18 MFD: 12.5x18 R4 Industrial - Rear 18.4 x 24 MFD: 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Compatible loaders: L545, L555 Loader Model 2670CL L545; L555 Loader Lift Height 2670CL: 115.4 in L545: 106 in; L555: 105 in Loader Lift Capacity (Full Height) 2670CL: 3122 lb L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb Loader Breakout Force 2670CL: 5225 lb L545: 3,131 lb; L555: 3,527 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
