▶ EngineEngine Manufacturer Mahindra FPT Engine Model Not Published R753 Engine Type Four-stroke, Turbocharged, Direct Injection, Water Cooled Diesel Engine Turbocharged, intercooled 3-cylinder diesel No. of Cylinders 3 3 Displacement 161.7 in³ 136 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 70 hp 70 hp PTO Power 53.8 hp 62 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water cooled Pressurized liquid with recirculating bypass Air Cleaner Not Published 2-stage Fuel System Direct injection Common rail direct injection (CRDI) Alternator 90 A, 12 V 75 A ▶ HydraulicsPump Type Not Published Dual engine-driven gear pumps, open center, fixed displacement Implement Flow 11.8 gpm 12 gpm Steering Flow Not Published 5.5 gpm Total Hydraulic Flow 16.7 gpm 17.5 gpm Overall Hydraulic Pump Flow 16.7 gpm 17.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity Not Published 17.2 gal Coolant Capacity Not Published 10.6 qt Crankcase Capacity Not Published 6.7 qt Transmission / Hydraulic System Capacity Not Published ROPS 2WD: 6.1 gal; ROPS 4WD: 6.6 gal Front Axle Fluid Capacity Not Published 4WD: 8.0 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2300 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT II with telescoping stabilizers & flex links Category II/I Hitch Lift Capacity 3528 lb 3,307 lb Hitch Lift Capacity (at 24”) Not Published 2,701 lb Lift Control Type Position and draft control Position control with mechanical draft control ▶ Transmission & DrivetrainTransmission Type Power Shuttle 8x8 synchronized shuttle No. of Speeds 12F / 12R 8F/8R Max Travel Speed (Forward) Not Published 19.1 mph (13.6x28 rear tires); 19.8 mph (14.9x28 rear tires) Max Travel Speed (Reverse) Not Published 20.2 mph (13.6x28 rear tires); 20.9 mph (14.9x28 rear tires) Clutch Dry single plate Dry, 11 in organic plate (LUK) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc brakes Individual mechanically actuated wet disc Seat Suspension & Adjustability Not Published Deluxe contoured suspension seat, adjusts to operator height Front Axle Type Not Published 4WD: limited-slip front axle with front differential lock, mechanical FWD engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 144.4 in ROPS 2WD: 129.5 in; ROPS 4WD: 134.0 in Overall Width 71.5 in ROPS 2WD: 66.5 in; ROPS 4WD: 67.5 in Wheelbase 83 in ROPS 2WD: 77.6 in; ROPS 4WD: 77.2 in Ground Clearance 15.7 in ROPS 2WD: 19.5 in; ROPS 4WD: 15.9 in Min. Turn Radius without Brakes Not Published ROPS 2WD: 122.0 in; ROPS 4WD: 190.9 in Height to Top of ROPS Not Published ROPS 2WD: 96.5 in; ROPS 4WD: 97.6 in Height to Top of ROPS (folded) Not Published ROPS 2WD: 75.9 in; ROPS 4WD: 77.0 in Height to Top of Cab Model 102 in Not Published ▶ WeightTractor Weight (Base) 5390 lb ROPS 2WD: 4,442 lb; ROPS 4WD: 5,059 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial R1 agricultural, R3 turf, R4 industrial R1 Agricultural - Front 9.5 x 20 8.3X24, 6 ply R1 Agricultural - Rear 14.9 x 28 14.9x28 R1, 6 ply R3 Turf - Front LSW305-521 Not Published R3 Turf - Rear LSW570-648 Not Published R4 Industrial - Front 10.5/80 x 18 12.5x18 R4 Industrial - Rear 18.4 x 24 18.4x24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) Loader Model 2670CL 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) Loader Lift Height 2670CL: 115.4 in 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in Loader Lift Capacity (Full Height) 2670CL: 3122 lb 616TL: 1,940 lb; 621TL: 3,549 lb; 626TL: 2,447 lb (at the pivot pin, full height) Loader Breakout Force 2670CL: 5225 lb 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in ahead of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
