▶ EngineEngine Manufacturer Mahindra Deutz Engine Model VNEF TCD 2.9 Engine Type Turbocharged, direct injection, liquid-cooled diesel 4-cylinder, turbocharged diesel No. of Cylinders 3 4 Displacement 161.7 in³ 177 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 70 hp 68 hp PTO Power 53.8 hp 62.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dual dry Dual dry Fuel System Direct Injection (mCRD fuel-injected) CRDI Alternator 90 A, 12 V 95 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 11.8 gpm 10.3 gpm Steering Flow 4.9 gpm 5.8 gpm Total Hydraulic Flow 16.7 gpm 16.1 gpm Overall Hydraulic Pump Flow 16.7 gpm 16.1 gpm Hydraulic System Type Open Center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Spool 6 (Floating/Regen); 4 (Spring/Floating) No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 18.5 gal 18.5 gal Coolant Capacity 9.5 qt 2.8 gal Crankcase Capacity 7.1 qt Not Published Transmission / Hydraulic System Capacity 11 gal 11.1 gal Front Axle Fluid Capacity 17.4 qt 4.3 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2300 rpm 540/750 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT II with Telescoping Stabilizers & Flex Links Category II Hitch Lift Capacity 3,528 lb 4,270 lb Hitch Lift Capacity (at 24”) 3,153 lb 3,153 lb Lift Control Type Position and draft control Position/Draft ▶ Transmission & DrivetrainTransmission Type Power Shuttle Synchro or power shuttle No. of Speeds 12F / 12R Not Published Max Travel Speed (Forward) 17.7 mph 23 mph Max Travel Speed (Reverse) 18.1 mph Not Published Clutch Dry Single Plate M: Dry Single Plate; PS: Wet Multi Plate Differential Lock & Limited Slip Options Differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Wet Disc Brake, Mechanical Wet disc Seat Suspension & Adjustability Seat with mechanical suspension, adjustable headrest, folding armrests Suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 144.4 in n/a Overall Width 71.5 in 72.4 in Wheelbase 83 in 84.7 in Ground Clearance 15.7 in 17.1 in Min. Turn Radius without Brakes Not Published 162.2 in Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102 in 103 in Overall Length n/a 155.6 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 5,390 lb 5,556 lb (with cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 6,708 lb (5,390 + 1,318, computed; 2670CL loader shipping weight) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial, R3 Turf Not Published R1 Agricultural - Front 9.5X20 9.5R20 R1 Agricultural - Rear 14.9X28 Not Published R3 Turf - Front LSW305-521 Not Published R3 Turf - Rear LSW570-648 Not Published R4 Industrial - Front 10.5/80X18 Not Published R4 Industrial - Rear 18.4X24 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System 2670CL: quick-attach adapter included Not Published Loader Model 2670CL L5068SL Loader Lift Height 2670CL: 115.4 in L5068SL: 124.8 in Loader Lift Capacity (Full Height) 2670CL: 3,122 lb at pivot pin to full height L5068SL: 3,122 lb Loader Breakout Force 2670CL: 5,225 lb L5068SL: 5,225 lb ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months
