▶ EngineEngine Manufacturer Mitsubishi Mitsubishi Engine Model Not Published S3L2 Engine Type Three cylinder, four cycle, valve in cylinder head, cross flow porting diesel Tier IV, four cycle, valve in cylinder head, naturally aspirated, water cooled diesel No. of Cylinders 3 3 Displacement 80.43 in³ 80.4 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 26 hp 25.6 hp PTO Power 23 hp 19 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled, pressurized, thermostat controlled bypass, impeller pump Water-cooled Air Cleaner Dry type with double filter Not Published Fuel System Indirect injection; Bosch M type ND-PFR (Denso) injection pump, throttle type injectors Not Published Alternator 50 A 50 A, 12 V ▶ HydraulicsPump Type Gear type, front mounted, engine driven Not Published Implement Flow 7.8 gpm 7.5 gpm Steering Flow 3.4 gpm 3.3 gpm Total Hydraulic Flow 11.2 gpm (7.8 + 3.4, computed) 10.8 gpm (7.5 + 3.3, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity Not Published 7.1 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent (3016 Gear Drive); Live (3016 Hydrostatic Drive) Independent (1526 Shuttle); Live (1526 HST) PTO Rear 540 rpm @ 2376 rpm 540 rpm Mid-PTO Availability Optional; 2000 rpm @ 2525 rpm Optional; 2000 rpm Category, 3-Point Hitch CAT I CAT I with telescopic stabilizers Hitch Lift Capacity Not Published 2646 lb Hitch Lift Capacity (at 24”) 1720 lb Not Published Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, constant mesh main with 2 ranges (3016 Gear Drive); Hydrostatic, 3 ranges (3016 Hydrostatic Drive) Constant mesh shuttle (1526 Shuttle); HST, 3 ranges (1526 HST) No. of Speeds 8F/8R (3016 Gear Drive); Infinite, 3 ranges (3016 Hydrostatic Drive) 8F/8R (1526 Shuttle); Infinite, 3 ranges (1526 HST) Max Travel Speed (Forward) 11.9 mph (3016 Gear Drive); 13.8 mph (3016 Hydrostatic Drive) Not Published Max Travel Speed (Reverse) 9.9 mph (3016 Gear Drive); 6.9 mph (3016 Hydrostatic Drive) Not Published Clutch Dry single disc, diaphragm type, 8.46 in Dry single disc Differential Lock & Limited Slip Options Mechanical differential lock, pedal actuated Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc, mechanical Wet disc Seat Suspension & Adjustability Not Published Deluxe suspension seat Front Axle Type Mechanical front drive (MFD), spiral bevel gear differential with bevel gear reductions Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 969 lbf Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121.3 in 121.3 in Overall Width 63 in 63 in Wheelbase 67.3 in Not Published Ground Clearance 11.4 in Not Published Min. Turn Radius without Brakes 7.9 ft (with brake applied) 7.9 ft Height to Top of ROPS 81.5 in 81.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2437 lb (3016 Gear Drive); 2459 lb (3016 Hydrostatic Drive) 2437 lb (1526 Shuttle); 2459 lb (1526 HST) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Ag, Industrial, Turf R1 Agricultural - Front 7x16 7x16 R1 Agricultural - Rear 11.2x24 11.2x24 R3 Turf - Front 25x8.5-14 25x8.5-14 R3 Turf - Rear 13.6x16 13.6x16 R4 Industrial - Front 27x8.50-15 27x8.5-15 R4 Industrial - Rear 15x19.5 15x19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model ML115 1526L Loader Lift Height ML115: 99 in 1526L: 84 in Loader Lift Capacity (Full Height) ML115: 1,650 lb 1526L: 1,560 lb Loader Breakout Force ML115: 2,650 lb 1526L: 2,795 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
