▶ EngineEngine Manufacturer Mitsubishi Mahindra Engine Model Not Published Not Published Engine Type 3-cylinder, overhead valve, cross-flow porting diesel Four-stroke, direct-injection water-cooled, diesel No. of Cylinders 3 4 Displacement 80.43 in³ 166.7 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 26 hp 41 hp PTO Power Shuttle: 23 hp; HST: 21.1 hp 31 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled, pressurized, thermostat controlled bypass, impeller pump Water-cooled Air Cleaner Dry type with double filter Not Published Fuel System Indirect injection; Bosch M-type ND-PFR (Denso) injection pump, throttle-type injectors Direct injection Alternator 50 A 45 A, 12 V ▶ HydraulicsPump Type Gear type, front mounted, engine driven Not Published Implement Flow 7.8 gpm 8.7 gpm Steering Flow 3.4 gpm 5.8 gpm Total Hydraulic Flow 11.2 gpm (7.8 + 3.4, computed) Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center, full-live hydraulic, with position and draft control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None standard (1 spool optional) No. of Optional Remote Valves 1 1 spool ▶ Fluid CapacityFuel Tank Capacity Not Published 14.55 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent (3016 Gear Drive); Live (3016 Hydrostatic Drive) Live PTO Rear 540 rpm @ 2376 rpm 540 rpm @ 2058 engine rpm Mid-PTO Availability Optional; 2000 rpm @ 2525 rpm Not Published Category, 3-Point Hitch CAT I Category I & II adjustable, with telescopic stabilizers Hitch Lift Capacity Not Published 3,525 lb Hitch Lift Capacity (at 24”) 1,720 lb Not Published Lift Control Type Position control Position & draft control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, constant-mesh main, 2 ranges (3016 Gear Drive); hydrostatic, 3 ranges (3016 Hydrostatic Drive) Sliding mesh No. of Speeds 8F/8R (3016 Gear Drive); infinite, 3 ranges (3016 Hydrostatic Drive) 8F / 2R Max Travel Speed (Forward) 11.9 mph (3016 Gear Drive); 13.8 mph (3016 Hydrostatic Drive) Not Published Max Travel Speed (Reverse) 9.9 mph (3016 Gear Drive); 6.9 mph (3016 Hydrostatic Drive) Not Published Clutch Dry single disc, diaphragm type, 8.46 in Dual Differential Lock & Limited Slip Options Mechanical differential lock, pedal actuated Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc, mechanical Fully enclosed dry disc Seat Suspension & Adjustability Not Published mComfort mechanical suspension seat Front Axle Type MFD, spiral bevel differential, bevel gear final drives Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 969 lbf Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121.3 in 115.3 in Overall Width 63 in 69.4 in Wheelbase 67.3 in Not Published Ground Clearance 11.4 in Not Published Min. Turn Radius without Brakes 7.9 ft (with brake applied) 9.7 ft (with brake applied) Height to Top of ROPS 81.5 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2,437 lb (3016 Gear Drive); 2,459 lb (3016 Hydrostatic Drive) 4,191 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural R1 Agricultural - Front 7x16 6X16 R1 Agricultural - Rear 11.2x24 12.4X28 R3 Turf - Front 25x8.5-14 Not Published R3 Turf - Rear 13.6x16 Not Published R4 Industrial - Front 27x8.50-15 Not Published R4 Industrial - Rear 15x19.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer style quick-attach coupler Loader Model ML115 4550-2L Loader Lift Height ML115: 99 in 4550-2L: 116.6 in Loader Lift Capacity (Full Height) ML115: 1,650 lb 4550-2L: 2,866 lb at pivot pins to full height Loader Breakout Force ML115: 2,350 lb 4550-2L: 4,978 lb at pivot pins ▶ WarrantyWarranty Length & Coverage Not Published 7-Year Limited Powertrain Warranty
