▶ EngineEngine Manufacturer Mitsubishi Yanmar Engine Model Not Published 3TNV88C-KJPT Engine Type Three Cylinders, Four Cycle, Valve in Cylinder Head, Cross Flow Porting 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 101.4 in³ 100.1 in³ Rated Engine Speed 2600 rpm 2800 rpm Engine Power (Gross) 34.5 hp 34.2 hp PTO Power Gear: 31 hp; Hydro: 29 hp 30.4 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Dry Type Air Cleaning System with Double Filter Dual element Fuel System 3016: BOSCH M type ND-PFR, DENSO; 3616: BOSCH-PFR Direct injection Alternator 55 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Front Mounted, Engine Driven, Pressure Loading Gear Type Two single-section external gear pumps, one each side of engine timing-gear cover Implement Flow 7.7 gpm at 2600 engine rpm 4.8 gpm Steering Flow 3.4 gpm at 2600 engine rpm 3.6 gpm Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 (optional) Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 10.0 gal Coolant Capacity Not Published 1.2 gal Crankcase Capacity Not Published 1.1 gal Transmission / Hydraulic System Capacity Not Published 9.2 gal Front Axle Fluid Capacity Not Published 1.0 gal ▶ PTO & HitchPTO Type Gear Drive: Independent PTO; Hydrostatic Drive: Live PTO (internal over-running clutch) Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) PTO Rear 540 rpm @ 2376 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Optional, 2000 rpm @ 2525 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2646 lb Not Published Hitch Lift Capacity (at 24”) 1720 lb 2081.2 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Gear Drive: Synchromesh on shuttle (forward-reverse) and main gear shift of constant mesh with two ranges of selective sliding gears; Hydrostatic Drive: HST with three ranges of selective sliding gears 8F/8R synchromesh shuttle shift gear transmission No. of Speeds Not Published 8F/8R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry, Single Disc, Diaphragm Type, 8.46 in Single dry traction clutch Differential Lock & Limited Slip Options Controlled by pedal, mechanically actuated (gear drive: RH step; hydrostatic drive: LH step) Differential lock: Yes; limited slip: Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet Disk Plate Type Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical Front Drive (MFD): Spiral Bevel Gear Type Differential with Bevel Gear Reductions MFWD (4WD) Front Axle Rating Not Published 1940 lb Drawbar Capacity 969 lbf 1102 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121.3 in 111.2 in Overall Width 3616 (43x16.00-20): 62 in 57.3 in Wheelbase 68.9 in 62.6 in Ground Clearance 3616 (28x8.50-15): 12.5 in 13.0 in Min. Turn Radius without Brakes 3616: 98.4 in (with brake assistance) (with brake applied) 6.9 ft (with brakes) (with brake applied) Height to Top of ROPS 3616 (43x16.00-20): 84.4 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 3616 CABIN (43x16.00-20): 83 in Not Published ▶ WeightTractor Weight (Base) Gear Drive: 2560 lb; Hydrostatic Drive: 2566 lb; Gear Drive Cabin: 3065 lb; Hydrostatic Drive Cabin: 3087 lb 3166 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7x16 7-14 R1 Agricultural - Rear 11.2x24 11.2-24 R3 Turf - Front 27x10.5-15 27X8.5-15 R3 Turf - Rear 41x14-20 41X14-20 R4 Industrial - Front 28x8.5-15 25X8.5-14 R4 Industrial - Rear 43x16-20 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model ML115 D160 Loader Lift Height ML115: 99 in 84.0 in Loader Lift Capacity (Full Height) ML115: 1,650 lb 1,186 lb Loader Breakout Force ML115: 2,650 lb 1,704 lb ▶ WarrantyWarranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
