▶ EngineEngine Manufacturer Mahindra Yanmar Engine Model MDI 2700R2 3TNV86CT-KJPT Engine Type Four stroke, direct injection, water-cooled diesel 4-cycle, inline, water-cooled diesel, turbocharged No. of Cylinders 4 3 Displacement 167 in³ 95.8 in³ Rated Engine Speed 2300 rpm 2800 rpm Engine Power (Gross) 41 hp 41.6 hp PTO Power 31 hp 36.3 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid Air Cleaner Not Published Dry Fuel System Direct injection Direct injection Alternator 36 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Two single-section external gear pumps, one either side of the engine Implement Flow 8.29 gpm 5.9 gpm Steering Flow 5 gpm 4.4 gpm Total Hydraulic Flow 13.29 gpm (8.29 + 5, computed) 10.3 gpm Overall Hydraulic Pump Flow Not Published 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves 1 Loader mast mounted SCV (optional); 4th/5th SCV (optional) ▶ Fluid CapacityFuel Tank Capacity 14.55 gal 9.7 gal Coolant Capacity Not Published 1.3 gal Crankcase Capacity Not Published 1.1 gal Transmission / Hydraulic System Capacity Not Published 9.2 gal Front Axle Fluid Capacity Not Published 1.0 gal ▶ PTO & HitchPTO Type Live Transmission driven PTO Rear 540 rpm @ 2058 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT I and II adjustable, with telescopic stabilizers Category I Hitch Lift Capacity 3,527 lb (4025 2WD); 3,525 lb (4025 4WD) Not Published Hitch Lift Capacity (at 24”) Not Published 1,670 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type Sliding mesh 8F/8R synchromesh shuttle shift gear transmission No. of Speeds 8F/2R 8F/8R Max Travel Speed (Forward) 14.3 mph (4025 2WD); 17.6 mph (4025 4WD) 12.9 mph Max Travel Speed (Reverse) 6.0 mph (4025 2WD); 7.5 mph (4025 4WD) Not Published Clutch Dual (2-stage) Single dry traction (mechanical) Differential Lock & Limited Slip Options Not Published Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Fully enclosed dry disc Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD Front Axle Rating Not Published 1,940 lb Drawbar Capacity Not Published 1,102 lb (maximum static vertical load) ▶ Dimensions & ManeuverabilityOverall Width 69.4 in (4025 2WD); 82 in (4025 4WD) 57.3 in Wheelbase Not Published 62 in Ground Clearance Not Published 14 in Min. Turn Radius without Brakes 9.6 ft (4025 2WD); 10.5 ft (4025 4WD) 6.9 ft (with brake applied) Height to Top of ROPS 88.0 in (4025 2WD); 93.7 in (4025 4WD) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 115.3 in (4025 2WD); 129 in (4025 4WD) 111.2 in ▶ WeightTractor Weight (Base) 4,389 lb (4025 2WD, operating weight); 4,950 lb (4025 4WD, operating weight) 2,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag (4025 2WD); Ag, Industrial (4025 4WD) R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 6x16 (4025 2WD); 9.5x16 (4025 4WD) 7-14 R1 Agricultural - Rear 12.4x28 11.2-24 R3 Turf - Front Not Published 27X8.50-15 R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12x16.5 (4025 4WD) 25X8.50-14 R4 Industrial - Rear 16.9x24 (4025 4WD) 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model ML333 (4025 2WD); ML334 (4025 4WD) D160 Loader Lift Height ML333: 116.6 in; ML334: 116.6 in 84 in (at pivot pin) Loader Lift Capacity (Full Height) ML333: 2,866 lb; ML334: 2,866 lb 1,186 lb (at pivot point, maximum height) Loader Breakout Force ML333: 4,978 lb; ML334: 4,978 lb 1,704 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
