▶ EngineEngine Manufacturer Mahindra Mahindra Engine Model NE342 MDI 2700R2 Engine Type Not Published Four stroke, direct injection, water-cooled diesel No. of Cylinders 3 4 Displacement 146 in³ 167 in³ Rated Engine Speed 2100 rpm 2300 rpm Engine Power (Gross) 42 hp 41 hp PTO Power 35 hp 31 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Not Published Fuel System Direct injection Direct injection Alternator Not Published 36 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11 gpm 8.29 gpm Steering Flow Not Published 5 gpm Total Hydraulic Flow Not Published 13.29 gpm (8.29 + 5, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity Not Published 14.55 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type 2WD: Continuous; 4WD: Independent Live PTO Rear 540/1000 rpm 540 rpm @ 2058 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Rear Type II/I CAT I and II adjustable, with telescopic stabilizers Hitch Lift Capacity 3968 lb 3527 lb (4025 2WD); 3525 lb (4025 4WD) Hitch Lift Capacity (at 24”) Not Published Not Published Lift Control Type Position and draft control Position and draft control ▶ Transmission & DrivetrainTransmission Type 2WD: constant mesh; 4WD: synchromesh shuttle Sliding mesh No. of Speeds 2WD: 8F/2R; 4WD: 8F/8R 8F/2R Max Travel Speed (Forward) Not Published 14.3 mph (4025 2WD); 17.6 mph (4025 4WD) Max Travel Speed (Reverse) Not Published 6.0 mph (4025 2WD); 7.5 mph (4025 4WD) Clutch Not Published Dual (2-stage) Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS Not Published Steering Power steering Hydrostatic power steering Brakes 2WD: dry disc; 4WD: wet disc Fully enclosed dry disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 145.4 in 115.3 in (4025 2WD); 129 in (4025 4WD) Overall Width 67.3 in 69.4 in (4025 2WD); 82 in (4025 4WD) Wheelbase Not Published Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 9.6 ft (4025 2WD); 10.5 ft (4025 4WD) Height to Top of ROPS Not Published 88.0 in (4025 2WD); 93.7 in (4025 4WD) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2WD: 4752 lb; 4WD: 5742 lb 4389 lb (4025 2WD); 4950 lb (4025 4WD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Ag (4025 2WD); Ag, Industrial (4025 4WD) R1 Agricultural - Front 2WD: 6-16; 4WD: 9.5-20 6x16 (4025 2WD); 9.5x16 (4025 4WD) R1 Agricultural - Rear 2WD: 13.6-28; 4WD: 14.9-26 12.4x28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12x16.5 (4025 4WD) R4 Industrial - Rear Not Published 16.9x24 (4025 4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 4WD: ML245; 2WD: ML260 ML333 (4025 2WD); ML334 (4025 4WD) Loader Lift Height ML245: 117.4 in; ML260: 107.5 in ML333: 116.6 in; ML334: 116.6 in Loader Lift Capacity (Full Height) ML245: 2480 lb; ML260: 2500 lb ML333: 2,866 lb; ML334: 2,866 lb Loader Breakout Force ML245: 4400 lb; ML260: 5000 lb ML333: 4,978 lb; ML334: 4,978 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
