▶ EngineEngine Manufacturer Mahindra Mitsubishi Engine Model NE342 K38 Engine Type Not Published 3-cylinder turbocharged and intercooled diesel No. of Cylinders 3 3 Displacement 146 in³ 101 in³ Rated Engine Speed 2100 rpm 2500 rpm Engine Power (Gross) 42 hp 41.6 hp PTO Power 35 hp Gear: 32.8 hp; HST: 31.6 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Direct injection Common rail direct injection with electronic engine management Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Engine-driven gear-type pump Implement Flow 11 gpm 11.6 gpm Steering Flow Not Published 6.8 gpm Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.6 gpm No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity Not Published 14.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type 2WD: Continuous; 4WD: Independent Independent, electro-hydraulically engaged PTO Rear 540/1000 rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Rear Type II/I Category I Hitch Lift Capacity 3968 lb Not Published Hitch Lift Capacity (at 24”) Not Published 2,535 lb Lift Control Type Position and draft control Position control; draft control optional ▶ Transmission & DrivetrainTransmission Type 2WD: constant mesh; 4WD: synchromesh shuttle 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST No. of Speeds 2WD: 8F/2R; 4WD: 8F/8R Power shuttle: 12F / 12R; Servo-HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet multi-disc (power shuttle) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock, right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS Drop-axle rear with bull gear final drives Steering Power steering Power steering, tilt steering wheel Brakes 2WD: dry disc; 4WD: wet disc Internal wet disc brakes, individual control via independent foot pedals Seat Suspension & Adjustability Not Published Deluxe suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Front Axle Type Not Published Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 145.4 in 130.7 in Overall Width 67.3 in 64.2 in Wheelbase Not Published 71.1 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 91.3 in ▶ WeightTractor Weight (Base) 2WD: 4752 lb; 4WD: 5742 lb ROPS: 3,638 lb; Cab: 4,068 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/75R16 front, 400/80R24 rear) R1 Agricultural - Front 2WD: 6-16; 4WD: 9.5-20 8-16 R1 Agricultural - Rear 2WD: 13.6-28; 4WD: 14.9-26 12.4-24 (13.6-24 optional) R3 Turf - Front Not Published 27x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 10-16.5 or 250/75R16 R4 Industrial - Rear Not Published 17.5L-24 or 400/80R24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published DL125: universal skid steer or compact quick-attach tool carrier Loader Model 4WD: ML245; 2WD: ML260 DL125 Loader Lift Height ML245: 117.4 in; ML260: 107.5 in DL125: 102.4 in Loader Lift Capacity (Full Height) ML245: 2480 lb; ML260: 2500 lb DL125: 1,840 lb Loader Breakout Force ML245: 4400 lb; ML260: 5000 lb DL125: 2,190 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
