▶ EngineEngine Manufacturer Mahindra Mahindra Engine Model NE342 CE-45 Engine Type Four stroke, direct injection, water-cooled diesel, 3 cylinders Four-stroke, naturally aspirated, direct injection, water cooled diesel No. of Cylinders 3 4 Displacement 152.4 in³ 166.7 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 44 hp 44 hp PTO Power 35 hp 36 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Not Published Dry dual element Fuel System Direct injection Direct Injection (mCRD fuel-injected) Alternator 36 A, 12 V 90 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 10.9 gpm 8.2 gpm Steering Flow 4.8 gpm ROPS: 4.1 gpm; Cab: 4.5 gpm Total Hydraulic Flow Not Published 12.7 gpm Overall Hydraulic Pump Flow Not Published 12.7 gpm Hydraulic System Type Open center with position and draft control Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 or 2 (optional) 1 (optional) ▶ Fluid CapacityFuel Tank Capacity Not Published 9 gal Coolant Capacity Not Published 1.85 gal Crankcase Capacity Not Published 1.98 gal Transmission / Hydraulic System Capacity Not Published 9.25 gal Front Axle Fluid Capacity Not Published 2.17 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2100 rpm 540 rpm @ 2650 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1 & 2 CAT I Hitch Lift Capacity 3,969 lb 2,646 lb Hitch Lift Capacity (at 24”) Not Published Not Published Lift Control Type Position and draft control Position Control ▶ Transmission & DrivetrainTransmission Type Forward-reverse synchro-shuttle Sync, shuttle with part synchromesh No. of Speeds 8F/8R 12F / 12R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dual dry with cerametallic lining Dry single plate Differential Lock & Limited Slip Options Not Published Bevel gears with diff-lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power Power steering Brakes Dry disc Wet Disc Brake, Mechanical Seat Suspension & Adjustability Not Published Seat with mechanical suspension, adjustable headrest, folding armrests Front Axle Type Not Published Center pin Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 72.5 in 63.2 in Wheelbase Not Published 67.7 in Ground Clearance Not Published 14.5 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 94.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 134 in (with ag tires) 119.3 in ▶ WeightTractor Weight (Base) 5,567 lb (operating weight) 3,285 lb Weight with ROPS and Loader Not Published 4,462 lb (3,285 + 1,177, computed; 698.7 gal loader shipping weight) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R4 Industrial R1 Agricultural - Front 9.5x20 8.3x16 R1 Agricultural - Rear 13.6x28 12.4x24 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 10.5/80x18 10-16.5 R4 Industrial - Rear 16.9x24 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 2645L: quick-attach adapter included Loader Model ML245 2645L (66 in bucket) Loader Lift Height ML245: 120 in (at pin) 2645L: 101.9 in Loader Lift Capacity (Full Height) ML245: 2,950 lb (full height, at pin) 2645L: 2,041 lb (at pivot pin) Loader Breakout Force ML245: 4,950 lb (at pin) 2645L: 3,430 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
