▶ EnginePTO Power — 38 hp @ 300 rpm Alternator — 55 A Air Cleaner — Not Published Engine Type — Four-stroke, direct-injection, turbocharged and intercooled, water-cooled diesel Fuel System — Direct injection Displacement — 166.2 in³ No. of Cylinders — 4 Rated Engine Speed — 2300 rpm Cooling System Type — Water-cooled Engine Manufacturer — Mahindra Engine Power (Gross) — 45 hp @ 300 rpm Engine Emissions Constraints — No DPF ▶ WeightWeight with ROPS and Loader — Not Published Weight with Cab and Loader — Not Applicable ▶ WarrantyWarranty Length & Coverage — 5-Year limited powertrain warranty ▶ HydraulicsPump Type — Not Published Steering Flow — 4.62 gpm Implement Flow — 8.71 gpm Total Hydraulic Flow — 13.3 gpm Hydraulic System Type — Open center Rear Remote Hydraulic Flow — Not Published Overall Hydraulic Pump Flow — 13.3 gpm No. of Optional Remote Valves — 1 additional (expandable to 2 total) No. of Standard Remote Valves — 1 standard ▶ PTO & HitchPTO Rear — 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm PTO Type — Independent Lift Control Type — Position & draft control Hitch Lift Capacity — Not Published Mid-PTO Availability — Not Applicable Category, 3-Point Hitch — CAT I & II with telescopic stabilizers & flex links Hitch Lift Capacity (at 24”) — 3748 lbs ▶ Tire OptionsR3 Turf - Rear — Not Applicable R3 Turf - Front — Not Applicable Tire Size & Options — R1 Agricultural or R4 Industrial R4 Industrial - Rear — 16.9X24 R4 Industrial - Front — 10.5/80X18 R1 Agricultural - Rear — 14.9X28 R1 Agricultural - Front — 9.5X20 ▶ Fluid CapacityCoolant Capacity — Not Published Crankcase Capacity — Not Published Fuel Tank Capacity — 17.1 gal Front Axle Fluid Capacity — Not Published Transmission / Hydraulic System Capacity — Not Published ▶ Loader & AttachmentsLoader Lift Height — 122 inches Loader Breakout Force — 5200 lbs Quick Attach Loader System — 5155-1.1 gal: Skid-steer style quick-attach coupler Loader Lift Capacity (Full Height) — 3100 lbs ▶ Transmission & DrivetrainClutch — Dual dry, with cerametallic lining No. of Speeds — 12F / 12R Transmission Type — Full synchromesh with forward/reverse synchro shuttle & constant mesh range Max Travel Speed (Forward) — 17.9 mph Max Travel Speed (Reverse) — Not Published Differential Lock & Limited Slip Options — Not Published ▶ Chassis, Steering & ControlsBrakes — Fully-enclosed 7-inch diameter dry disc Steering — Hydrostatic power steering with tilt steering wheel Frame Type — Not Published Front Axle Type — Not Published Drawbar Capacity — Not Published Front Axle Rating — Not Published Seat Suspension & Adjustability — Adjustable seat with soft-coil suspension ▶ Dimensions & ManeuverabilityWheelbase — 74.8 inches Overall Width — 80.3 inches Ground Clearance — 15.2 inches Height to Top of ROPS — 60.6 inches Height to Top of Cab Model — Not Applicable Height to Top of ROPS (folded) — Not Published Min. Turn Radius without Brakes — Not Published Overall Length with 3-Point Hitch — 136.6 inches
