▶ EngineEngine Manufacturer Mahindra Mitsubishi Engine Model Not Published K38 Engine Type Four-stroke, direct-injection water-cooled, diesel 3-cylinder turbocharged and intercooled diesel No. of Cylinders 4 3 Displacement 166.7 in³ 101 in³ Rated Engine Speed 2300 rpm 2500 rpm Engine Power (Gross) 41 hp 41.6 hp PTO Power 31 hp Gear: 32.8 hp; HST: 31.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Direct injection Common-rail, direct injection, electronic engine management Alternator 45 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Engine-driven gear-type pump Implement Flow 8.7 gpm 11.6 gpm Steering Flow 5.8 gpm 6.8 gpm Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center, full-live hydraulic, with position and draft control Open center Rear Remote Hydraulic Flow Not Published 11.6 gpm No. of Standard Remote Valves None 1 No. of Optional Remote Valves 1 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 14.55 gal 14.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live Independent, electro-hydraulically engaged PTO Rear 540 rpm @ 2058 engine rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I & II adjustable, with telescopic stabilizers Category I Hitch Lift Capacity 3,525 lb Not Published Hitch Lift Capacity (at 24”) Not Published 2,535 lb Lift Control Type Position & draft control Position control; draft control optional ▶ Transmission & DrivetrainTransmission Type Sliding mesh 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST No. of Speeds 8F / 2R Power shuttle: 12F / 12R; Servo-HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dual Wet multi-disc (power shuttle) Differential Lock & Limited Slip Options Not Published Mechanical engagement via heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Drop-axle rear with bull gear final drives Steering Hydrostatic power steering Power steering, tilt steering wheel Brakes Fully enclosed dry disc Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability mComfort mechanical suspension seat Suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Front Axle Type Not Published Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 69.4 in 64.2 in Wheelbase Not Published 71.1 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.7 ft (with brake applied) Not Published Height to Top of ROPS 88 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 91.3 in Overall Length 115.3 in 130.7 in ▶ WeightTractor Weight (Base) 4,191 lb (operating weight) ROPS: 3,638 lb; Cab: 4,068 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/75R16 front, 400/80R24 rear) R1 Agricultural - Front 6X16 8-16 R1 Agricultural - Rear 12.4X28 12.4-24 (13.6-24 optional) R3 Turf - Front Not Published 27x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Applicable 10-16.5 or 250/75R16 R4 Industrial - Rear Not Applicable 17.5L-24 or 400/80R24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style quick-attach coupler DL125: universal skid steer or exclusive compact quick-attach implement tool carrier Loader Model 4550-2L DL125 Loader Lift Height 116.6 in DL125: 102.4 in (at pivot pin) Loader Lift Capacity (Full Height) 2,866 lb at pivot pins to full height DL125: 1,840 lb (at pivot pin, full height) Loader Breakout Force 4,978 lb at pivot pins DL125: 2,190 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty 5-year powertrain warranty
