▶ EngineEngine Manufacturer Mahindra Yanmar Engine Model MDI 2700 R2 3TNV84T-KJT Engine Type Four-stroke, direct-injection water-cooled, diesel 3-cylinder, direct injection, liquid-cooled diesel No. of Cylinders 4 3 Displacement 166.7 in³ 91.5 in³ Rated Engine Speed 2300 rpm 2800 rpm Engine Power (Gross) 41 hp 41 hp PTO Power 31 hp 32.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type with safety cartridge and dust unloader valve Dry type with safety element Fuel System Direct injection Direct injection, self-bleeding in-line fuel pump, electric shutoff Alternator 45 A, 12 V 40 A ▶ HydraulicsPump Type Not Published Dual tandem gear pump Implement Flow 8.7 gpm 9.2 gpm Steering Flow 5.8 gpm 5.7 gpm Total Hydraulic Flow 8.7 gpm 14.8 gpm Overall Hydraulic Pump Flow 8.7 gpm 14.8 gpm Hydraulic System Type Open center, full-live hydraulic, with position and draft control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 2 No. of Optional Remote Valves 1 spool Not Published ▶ Fluid CapacityFuel Tank Capacity 14.55 gal 11.5 gal Coolant Capacity 2.25 gal 1.4 gal Crankcase Capacity 2.14 gal 4.5 qt Transmission / Hydraulic System Capacity 10.57 gal 8.3 gal Front Axle Fluid Capacity 2.24 gal 1.2 gal ▶ PTO & HitchPTO Type Live Independent, wet disk clutch PTO Rear 540 rpm @ 2058 engine rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I & II adjustable, with telescopic stabilizers Category 1 Hitch Lift Capacity 3,527 lb 2,530 lb Hitch Lift Capacity (at 24”) Not Published 2,200 lb Lift Control Type Position & draft control Position control ▶ Transmission & DrivetrainTransmission Type Full constant mesh 2-range hydrostatic No. of Speeds 8F / 2R Infinite forward and reverse, 2 ranges Max Travel Speed (Forward) 17.6 mph 13 mph Max Travel Speed (Reverse) 7.53 mph 12.6 mph Clutch Dual Wet disk Differential Lock & Limited Slip Options Foot-operated differential lock Ball, ramp and pin differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Fixed ROPS; four-wheel drive standard Steering Hydrostatic power steering Hydrostatic power steering Brakes Fully enclosed dry disc Wet disk Seat Suspension & Adjustability mComfort mechanical suspension seat Not Published Front Axle Type Not Published Mechanical front wheel drive (MFWD), standard, all ranges Front Axle Rating Not Published 3,197 lb Drawbar Capacity Not Published 882 lb ▶ Dimensions & ManeuverabilityOverall Width 82.6 in 63 in (minimum, R1 rear tires); 65.8 in (maximum, R4 rear tires) Wheelbase 76.7 in 68 in Ground Clearance 8.7 in 14.7 in (front axle) Min. Turn Radius without Brakes 147.63 in Not Published Height to Top of ROPS 92.6 in 87.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 128.9 in 120.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 5,192 lb (operating weight) 2,899 lb (with ROPS, 3-point hitch and all fluids) Weight with ROPS and Loader 6,746 lb (5,192 + 1,554, computed; 4550-1.1 gal loader transport weight) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Industrial (standard); Agri (optional) R1 bar tread (8.00-16 front, 14.9-24 rear) or R4 industrial (10.0-16.5 front, 17.5L-R24 rear) R1 Agricultural - Front 9.5X16 8.00-16 R1 Agricultural - Rear 12.4X28 14.9-24 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12X16.5 10.0-16.5 R4 Industrial - Rear 16.9X24 17.5L-R24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style quick-attach coupler Not Published Loader Model 4550-4L 320R Loader Lift Height 116.6 in H165: 103 in; 320R: 103 in Loader Lift Capacity (Full Height) 2,866 lb at pivot pins to full height 320R: 1,393 lb (to maximum height at pivot pin) Loader Breakout Force 4,978 lb at pivot pins H165: 3,769 lbf; 320R: 3,769 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty 3-year / 2,000-hour limited warranty (as sold new)
