▶ EngineEngine Manufacturer Mahindra Mahindra Engine Model MDI 2700 R1 CE-45 Engine Type Four-stroke, direct-injection water-cooled, diesel Four-stroke, naturally aspirated, direct injection, water cooled diesel No. of Cylinders 4 4 Displacement 166.7 in³ 166.7 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 48 hp 44 hp PTO Power 38 hp 36 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Dry type with safety cartridge and dust unloader valve Dry dual element Fuel System Direct injection Direct Injection (mCRD fuel-injected) Alternator 45 A, 12 V 90 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 8.7 gpm 8.2 gpm Steering Flow 5 gpm ROPS: 4.1 gpm; Cab: 4.5 gpm Total Hydraulic Flow Not Published 12.7 gpm Overall Hydraulic Pump Flow Not Published 12.7 gpm Hydraulic System Type Open center, full-live hydraulic, with position and draft control Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 (spool) standard Not Published No. of Optional Remote Valves Not Published 1 (optional) ▶ Fluid CapacityFuel Tank Capacity 14.55 gal 9 gal Coolant Capacity 2.25 gal 1.85 gal Crankcase Capacity 2.14 gal 1.98 gal Transmission / Hydraulic System Capacity 10.57 gal 9.25 gal Front Axle Fluid Capacity 2.24 gal 2.17 gal ▶ PTO & HitchPTO Type Live Independent PTO Rear 540 rpm @ 2058 engine rpm 540 rpm @ 2650 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I & II adjustable, with telescopic stabilizers CAT I Hitch Lift Capacity 3,527 lb 2,646 lb Hitch Lift Capacity (at 24”) Not Published Not Published Lift Control Type Position & draft control Position Control ▶ Transmission & DrivetrainTransmission Type Full constant mesh Sync, shuttle with part synchromesh No. of Speeds 8F / 2R 12F / 12R Max Travel Speed (Forward) 17.6 mph Not Published Max Travel Speed (Reverse) 7.53 mph Not Published Clutch Dual Dry single plate Differential Lock & Limited Slip Options Foot-operated differential lock Bevel gears with diff-lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Fully enclosed dry disc Wet Disc Brake, Mechanical Seat Suspension & Adjustability mComfort mechanical suspension seat Seat with mechanical suspension, adjustable headrest, folding armrests Front Axle Type Not Published Center pin Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 82.6 in 63.2 in Wheelbase 76.7 in 67.7 in Ground Clearance 8.7 in 14.5 in Min. Turn Radius without Brakes 147.63 in Not Published Height to Top of ROPS 93.7 in 94.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 127 in 119.3 in ▶ WeightTractor Weight (Base) 5,192 lb (operating weight) 3,285 lb Weight with ROPS and Loader Not Published 4,462 lb (3,285 + 1,177, computed; 698.7 gal loader shipping weight) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Industrial (standard); Agri (optional) R1 Agricultural, R4 Industrial R1 Agricultural - Front 9.5X16 8.3x16 R1 Agricultural - Rear 12.4X28 12.4x24 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12 x 16.5 10-16.5 R4 Industrial - Rear 16.9X24 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style quick-attach coupler 2645L: quick-attach adapter included Loader Model 4550-4L 2645L (66 in bucket) Loader Lift Height 116.6 in 2645L: 101.9 in Loader Lift Capacity (Full Height) 2,866 lb at pivot pins to full height 2645L: 2,041 lb (at pivot pin) Loader Breakout Force 4,978 lb at pivot pins 2645L: 3,430 lb ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty Not Published
