▶ EngineEngine Manufacturer Daedong Kubota Engine Model 4B243LW V2403-CR-E4-GL5 Engine Type Indirect injection diesel Naturally aspirated, multi-valve, liquid-cooled diesel No. of Cylinders 4 4 Displacement 148.6 in³ 148.5 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 49 hp 49 hp PTO Power 41.5 hp 39.5 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element Fuel System Indirect injection Electronic CRS (Common Rail System) Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 9.5 gpm 9.4 gpm Steering Flow 5 gpm 4.7 gpm Total Hydraulic Flow 14.5 gpm (9.5 + 5, computed) 14.1 gpm Overall Hydraulic Pump Flow Not Published 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 None standard (up to 3 optional) No. of Optional Remote Valves 3 Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 16 gal 13.5 gal Coolant Capacity Not Published 8.7 qt Crankcase Capacity Not Published 8.7 qt Transmission / Hydraulic System Capacity Not Published 11.4 gal Front Axle Fluid Capacity Not Published 8.9 qt ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 rpm @ 2600 rpm 540 rpm @ 2475 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch CAT I with check chains (5010 4WD Gear); CAT I with check chains (5010 Gear Cab); CAT I with telescopic check chains (5010 HST Cab) SAE Category I Hitch Lift Capacity 3,314 lb 3,858 lb Hitch Lift Capacity (at 24”) Not Published 2,756 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Constant mesh (5010 4WD Gear); constant mesh (5010 Gear Cab); HST, 3 ranges (5010 HST Cab) Hydrostatic No. of Speeds 9F/3R (5010 4WD Gear); 9F/3R (5010 Gear Cab); infinite, 3 ranges (5010 HST Cab) 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 15.3 mph (5010 4WD Gear); 15.3 mph (5010 Gear Cab); 17.7 mph (5010 HST Cab) 16.8 mph Max Travel Speed (Reverse) 9.2 mph (5010 4WD Gear); 9.2 mph (5010 Gear Cab); 17.7 mph (5010 HST Cab) 15.1 mph Clutch Single plate, dry (5010 4WD Gear); single plate, dry (5010 Gear Cab); n/a (5010 HST Cab) Not Published Differential Lock & Limited Slip Options Not Published Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Hydrostatic power steering Brakes Wet disc Wet disc type, mechanically activated Seat Suspension & Adjustability Adjustable suspension seat Deluxe suspension seat with swivel; Air-Ride seat (optional) Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 71.1 in (5010 4WD Gear); 71.5 in (5010 Gear Cab); 71.5 in (5010 HST Cab) 66.5 in Wheelbase Not Published 74.6 in Ground Clearance Not Published 14.4 in Min. Turn Radius without Brakes 11 ft 8.9 ft (with brake applied) Height to Top of ROPS 101 in 97.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 98.4 in Not Applicable Overall Length 134 in (with industrial tires) 129.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,836 lb (5010 4WD Gear, operating weight); 4,078 lb (5010 Gear Cab, operating weight); 4,078 lb (5010 HST Cab, operating weight) 3,847 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Golf (turf) R1 Agricultural; R3 Turf (Option 1) or R3 LSW Turf (Option 2); R4 Industrial R1 Agricultural - Front 9.5x16 8.3-16 R1 Agricultural - Rear 14.9x24 14.9-24 R3 Turf - Front LSW305-521 29x12.50-15 R3 Turf - Rear LSW570-648 44x18-20 R4 Industrial - Front 12x16.5 10-16.5 R4 Industrial - Rear 16.9x24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model ML151 (5010 4WD Gear); ML156 (5010 Gear Cab, 5010 HST Cab) LA1105 Loader Lift Height ML151: 115.4 in; ML156: 115.4 in Not Published Loader Lift Capacity (Full Height) ML151: 3,122 lb; ML156: 3,122 lb Not Published Loader Breakout Force ML151: 5,225 lb; ML156: 5,225 lb LA555: 2,030 lb; LA805: 2,549 lb; LA1055: 3,171 lb ▶ WarrantyWarranty Length & Coverage 5-year limited warranty Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
