▶ EngineEngine Manufacturer Daedong Shibaura Engine Model 4B243LW N4LDI-T Engine Type Indirect injection diesel 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 148.6 in³ 135.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 49 hp 48.8 hp PTO Power 41.5 hp Gear: 41.4 hp; HST: 39 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Primary and secondary elements Fuel System Indirect injection Electronically controlled high-pressure common rail Alternator 50 A, 12 V 90 A ▶ HydraulicsPump Type Not Published Gear-type single pump Implement Flow 9.5 gpm Not Published Steering Flow 5 gpm Not Published Total Hydraulic Flow 14.5 gpm (9.5 + 5, computed) 12.4 gpm Overall Hydraulic Pump Flow Not Published 12.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 0 No. of Optional Remote Valves 3 1 factory-installed; up to 3 field-installed ▶ Fluid CapacityFuel Tank Capacity 16 gal 14 gal Coolant Capacity Not Published 1.66 gal Crankcase Capacity Not Published 1.53 gal Transmission / Hydraulic System Capacity Not Published 10.04 gal Front Axle Fluid Capacity Not Published 2.21 gal ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulically engaged PTO Rear 540 rpm @ 2600 rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published No mid-PTO Category, 3-Point Hitch CAT I with check chains Category I and II Hitch Lift Capacity 3314 lb Not Published Hitch Lift Capacity (at 24”) Not Published 2,425 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Constant mesh (5010 4WD Gear); Constant mesh (5010 Gear Cab); HST, 3 ranges (5010 HST Cab) Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST No. of Speeds 9F/3R (5010 4WD Gear); 9F/3R (5010 Gear Cab); Infinite, 3 ranges (5010 HST Cab) Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) Max Travel Speed (Forward) 15.3 mph (5010 4WD Gear); 15.3 mph (5010 Gear Cab); 17.7 mph (5010 HST Cab) Not Published Max Travel Speed (Reverse) 9.2 mph (5010 4WD Gear); 9.2 mph (5010 Gear Cab); 17.7 mph (5010 HST Cab) Not Published Clutch Single plate, dry (5010 4WD Gear); Single plate, dry (5010 Gear Cab); N/A (5010 HST Cab) Dry single-disc Differential Lock & Limited Slip Options Not Published Mechanical engagement (Gear: right side heel pedal; HST: left side heel pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Power steering Brakes Wet disc Internal wet disc, 2 pedals (Gear: right hand; HST: left hand) Seat Suspension & Adjustability Adjustable suspension seat Suspended vinyl seat with retractable seatbelt Front Axle Type Not Published Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 134 in 133 in Overall Width 71.1 in (5010 4WD Gear); 71.5 in (5010 Gear Cab); 71.5 in (5010 HST Cab) 74 in Wheelbase Not Published 78 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 11 ft Not Published Height to Top of ROPS 101 in 104 in Height to Top of ROPS (folded) Not Published 80 in Height to Top of Cab Model 98.4 in Not Published ▶ WeightTractor Weight (Base) 3836 lb (5010 4WD Gear); 4078 lb (5010 Gear Cab); 4078 lb (5010 HST Cab) Gear: 3,836 lb; HST: 3,880 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Golf (turf) R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear R1 Agricultural - Front 9.5x16 9.5x16 R1 Agricultural - Rear 14.9x24 13.6x28; 16.9x24 R3 Turf - Front LSW305-521 27x10.50-15 R3 Turf - Rear LSW570-648 44x18.00-20 R4 Industrial - Front 12x16.5 10-16.5 R4 Industrial - Rear 16.9x24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published L135E: optional skid steer tool carrier Loader Model ML151 (5010 4WD Gear); ML156 (5010 Gear Cab, 5010 HST Cab) L135E Loader Lift Height ML151: 115.4 in; ML156: 115.4 in L135E: 110.2 in Loader Lift Capacity (Full Height) ML151: 3,122 lb; ML156: 3,122 lb L135E: 2,430 lb Loader Breakout Force ML151: 5,225 lb; ML156: 5,225 lb L135E: 2,870 lb ▶ WarrantyWarranty Length & Coverage 5-year limited warranty 5-year powertrain warranty
