▶ EngineEngine Manufacturer Daedong Shibaura Engine Model 4B243LW N4LDI-T Engine Type Indirect injection diesel 4-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 4 4 Displacement 148.6 in³ 135.2 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 49 hp 48.8 hp PTO Power 41.5 hp 38.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Indirect injection Common rail direct injection Alternator 50 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Engine-driven gear-type pump Implement Flow 9.5 gpm Not Published Steering Flow 5 gpm Not Published Total Hydraulic Flow 14.5 gpm (9.5 + 5, computed) Not Published Overall Hydraulic Pump Flow Not Published 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves 1 Cab: 1 pair No. of Optional Remote Valves 3 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 16 gal 14 gal Coolant Capacity Not Published 7.08 qt Crankcase Capacity Not Published 6.87 qt Transmission / Hydraulic System Capacity Not Published 12x12 Power Shuttle: 10.04 gal; HST: 9.25 gal Front Axle Fluid Capacity Not Published 9 qt ▶ PTO & HitchPTO Type Independent Independent, with soft-start feature PTO Rear 540 rpm @ 2600 rpm 540 rpm (6-spline) Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch CAT I with check chains (5010 4WD Gear); CAT I with check chains (5010 Gear Cab); CAT I with telescopic check chains (5010 HST Cab) Category I with extendable ball ends Hitch Lift Capacity 3,314 lb Not Published Hitch Lift Capacity (at 24”) Not Published 3,086 lb Lift Control Type Position control Draft control optional ▶ Transmission & DrivetrainTransmission Type Constant mesh (5010 4WD Gear); constant mesh (5010 Gear Cab); HST, 3 ranges (5010 HST Cab) 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds 9F/3R (5010 4WD Gear); 9F/3R (5010 Gear Cab); infinite, 3 ranges (5010 HST Cab) 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) 15.3 mph (5010 4WD Gear); 15.3 mph (5010 Gear Cab); 17.7 mph (5010 HST Cab) Not Published Max Travel Speed (Reverse) 9.2 mph (5010 4WD Gear); 9.2 mph (5010 Gear Cab); 17.7 mph (5010 HST Cab) Not Published Clutch Single plate, dry (5010 4WD Gear); single plate, dry (5010 Gear Cab); n/a (5010 HST Cab) Single stage dry type Differential Lock & Limited Slip Options Not Published Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering, tilt Power steering Brakes Wet disc Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Adjustable suspension seat Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Front Axle Type Not Published Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 71.1 in (5010 4WD Gear); 71.5 in (5010 Gear Cab); 71.5 in (5010 HST Cab) 65.4 in Wheelbase Not Published 77.9 in Ground Clearance Not Published 14.8 in Min. Turn Radius without Brakes 11 ft Not Published Height to Top of ROPS 101 in 102.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 98.4 in 92.9 in Overall Length 134 in (with industrial tires) 132.3 in ▶ WeightTractor Weight (Base) 3,836 lb (5010 4WD Gear, operating weight); 4,078 lb (5010 Gear Cab, operating weight); 4,078 lb (5010 HST Cab, operating weight) 12x12 Power Shuttle: 3,946 lb; HST: 4,045 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Golf (turf) Agricultural, Turf, Industrial, Snow R1 Agricultural - Front 9.5x16 9.5x16 R1 Agricultural - Rear 14.9x24 13.6x28 R3 Turf - Front LSW305-521 27x10.50-15 R3 Turf - Rear LSW570-648 44x18.00-20 R4 Industrial - Front 12x16.5 10-16.5 R4 Industrial - Rear 16.9x24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published DL135: Skid steer quick attach Loader Model ML151 (5010 4WD Gear); ML156 (5010 Gear Cab, 5010 HST Cab) DL135 Loader Lift Height ML151: 115.4 in; ML156: 115.4 in DL135: 111 in (at pivot pin) Loader Lift Capacity (Full Height) ML151: 3,122 lb; ML156: 3,122 lb DL135: 2,610 lb (at pivot pin, full height) Loader Breakout Force ML151: 5,225 lb; ML156: 5,225 lb DL135: 4,000 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year limited warranty 5-year powertrain warranty
