▶ EngineEngine Manufacturer Mahindra KIOTI (Daedong) Engine Model Not Published 3F183T Engine Type 5145: Four-stroke, Naturally Aspirated, Direct Injection, Water Cooled Diesel Engine; 5155: Four-stroke, Turbocharged, Direct Injection, Water Cooled Diesel Engine KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 4 3 Displacement 166.2 in³ 111.4 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 38 hp 33.9 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Not Published Dry type element Fuel System Not Published Common Rail Direct Injection (CRDI) Alternator 55 A, 12 V Not Published ▶ HydraulicsPump Type Open center; adjustable lower links with stabilizer Gear Implement Flow 8.71 gpm 9.6 gpm Steering Flow 4.62 gpm 8.2 gpm Total Hydraulic Flow Not Published 17.9 gpm Overall Hydraulic Pump Flow Not Published 17.9 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 (optional second rear valve) 1 ▶ Fluid CapacityFuel Tank Capacity 17.1 gal 14.8 gal Coolant Capacity Not Published 2.0 gal Crankcase Capacity Not Published 1.58 gal Transmission / Hydraulic System Capacity Not Published 11.89 gal Front Axle Fluid Capacity Not Published 1.8 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2300 rpm; 540E @ 1725 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch CAT I & II w/ Telescopic Stabilizers & Flex Links Category I Hitch Lift Capacity 3748 lb 3,538 lb Hitch Lift Capacity (at 24”) Not Published 3,177 lb Lift Control Type Not Published Position with Draft Control ▶ Transmission & DrivetrainTransmission Type Full Synchromesh with forward/reverse synchro shuttle & constant mesh range Hydrostatic No. of Speeds 12F / 12R 3 Range Max Travel Speed (Forward) Not Published 16.52 mph Max Travel Speed (Reverse) Not Published 16.52 mph Clutch Dual Dry with Cerametallic Lining Not Published Differential Lock & Limited Slip Options Not Published Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Tilt, power-assisted steering Hydrostatic Power Steering Brakes Fully-enclosed, 7-in Diameter, Dry Disc Wet Multi Disc Seat Suspension & Adjustability Not Published Adjustable Seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 139.6 in Overall Width Not Published 65.6 in Wheelbase 77.9 in 75.6 in Ground Clearance 5145: 15.2 in; 5155: 16.4 in 13.8 in Min. Turn Radius without Brakes 10.8 ft 9.8 ft Height to Top of ROPS 60.6 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94.1 in ▶ WeightTractor Weight (Base) 5390 lb 4,309 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5 x 20 8-16 R1 Agricultural - Rear 14.9 x 28 13.6-24 R3 Turf - Front Not Published 29-12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front 10.5/80x18 10-16.5 R4 Industrial - Rear 16.9 x 24 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model 5155-4L KL6010 Loader Lift Height 5155-4L: 122 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) 5155-4L: 3100 lb KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force 5155-4L: 5200 lb KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year, 3000-hour limited powertrain warranty Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
