Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Every published spec, side by side, including the details the graphs above don't chart.
Spec
Mahindra5100
Mahindra2545
Engine Manufacturer
Mahindra
Mahindra
Engine Model
Not Published
Not Published
Engine Type
5145: Four-stroke, Naturally Aspirated, Direct Injection, Water Cooled Diesel Engine; 5155: Four-stroke, Turbocharged, Direct Injection, Water Cooled Diesel Engine
Four-stroke, direct-injection, turbo-charged and intercooled diesel
No. of Cylinders
4
3
Displacement
166.2 in³
161.5 in³
Rated Engine Speed
2300 rpm
2600 rpm
Engine Power (Gross)
45 hp
44 hp
PTO Power
38 hp
39 hp
Engine Emissions Constraints
Not Published
Tier 4
Cooling System Type
Not Published
Not Published
Air Cleaner
Not Published
Not Published
Fuel System
Not Published
Direct injection
Alternator
55 A, 12 V
90 A, 12 V
Pump Type
Open center; adjustable lower links with stabilizer
Not Published
Implement Flow
8.71 gpm
8.2 gpm
Steering Flow
4.62 gpm
4.5 gpm
Total Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
Not Published
Not Published
Hydraulic System Type
Open center
Open Center with position control
Rear Remote Hydraulic Flow
Not Published
Not Published
No. of Standard Remote Valves
1
Not Published
No. of Optional Remote Valves
1 (optional second rear valve)
1 spool optional
Fuel Tank Capacity
17.1 gal
16 gal
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Front Axle Fluid Capacity
Not Published
Not Published
PTO Type
Independent
Independent
PTO Rear
540 rpm @ 2300 rpm; 540E @ 1725 rpm
540 rpm @ 2650 rpm
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
CAT I & II w/ Telescopic Stabilizers & Flex Links
CAT I with telescoping stabilizers & flex link ends
Hitch Lift Capacity
3748 lb
Not Published
Hitch Lift Capacity (at 24”)
Not Published
Not Published
Lift Control Type
Not Published
Not Published
Transmission Type
Full Synchromesh with forward/reverse synchro shuttle & constant mesh range
