▶ EngineEngine Manufacturer Mahindra LS Mtron Engine Model DH45 L3C19-T Engine Type Four-stroke, naturally aspirated, direct injection, water-cooled diesel Not Published No. of Cylinders 4 3 Displacement 166.2 in³ 115.9 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 38 hp 36 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Replaceable dry element Fuel System Direct injection Not Published Alternator 55 A 70 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 8.71 gpm 8.2 gpm Steering Flow 4.62 gpm Hydro: 5.3 gpm; Gear: 4.2 gpm Total Hydraulic Flow 13.3 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow 13.3 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves One 1 No. of Optional Remote Valves One (optional second rear valve) 2 ▶ Fluid CapacityFuel Tank Capacity 17.1 gal 10.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm 540 rpm Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch CAT I & II with telescopic stabilizers & flex links Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) Not Published 2,756 lb Lift Control Type Position control Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type Full synchromesh with forward/reverse synchro shuttle and constant-mesh range 3-range hydrostatic (optional) No. of Speeds 12F / 12R 3 ranges Max Travel Speed (Forward) 17.9 mph 17.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dual dry with cerametallic lining n/a (no clutch on hydrostatic) Differential Lock & Limited Slip Options Not Published Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering with tilt steering wheel Power steering Brakes Fully-enclosed, 7-in diameter, dry disc Wet multi-disc Seat Suspension & Adjustability Adjustable seat with contoured cushions, armrests and a soft-coil suspension Deluxe seat with armrests and an adjustable backrest Front Axle Type Not Published Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 74.8 in 69.1 in Wheelbase 77.9 in 73.2 in Ground Clearance 15.2 in Not Published Min. Turn Radius without Brakes 12.8 ft (3.9 m) Not Published Height to Top of ROPS Not Published 97.1 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model Not Published 93.3 in Overall Length 136.6 in 128.1 in ▶ WeightTractor Weight (Base) 5,390 lb 3,770 lb Weight with ROPS and Loader 6,690 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural or R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 9.5 x 20 9.5-16 R1 Agricultural - Rear 14.9 x 28 13.6-24 R3 Turf - Front Not Published 28x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front 10.5/80 x 18 12-16.5 R4 Industrial - Rear 16.9 x 24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style quick-attach coupler Quick-Attach faceplate; mid-mount frame for fast loader connect and disconnect (L360A) Loader Model 5155-4L (front loader); 65B (rear backhoe) L360A Loader Lift Height 122 in 112 in Loader Lift Capacity (Full Height) 3,100 lb 1,830 lb at 31.5 in. forward of pivot pin Loader Breakout Force 5,200 lb 3,114 lbf ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty Basic 2 years; powertrain 4 additional years (6-year, 72-month total)
