▶ EngineEngine Manufacturer Mahindra Mahindra Engine Model DH45 MDI 2700 R1 Engine Type Four-stroke, naturally aspirated, direct injection, water-cooled diesel Four-stroke, direct-injection water-cooled, diesel No. of Cylinders 4 4 Displacement 166.2 in³ 166.7 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 45 hp 48 hp PTO Power 38 hp 38 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Dry type with safety cartridge and dust unloader valve Fuel System Direct injection Direct injection Alternator 55 A 45 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 8.71 gpm 8.7 gpm Steering Flow 4.62 gpm 5 gpm Total Hydraulic Flow 13.3 gpm Not Published Overall Hydraulic Pump Flow 13.3 gpm Not Published Hydraulic System Type Open center Open center, full-live hydraulic, with position and draft control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves One 1 (spool) standard No. of Optional Remote Valves One (optional second rear valve) Not Published ▶ Fluid CapacityFuel Tank Capacity 17.1 gal 14.55 gal Coolant Capacity Not Published 2.25 gal Crankcase Capacity Not Published 2.14 gal Transmission / Hydraulic System Capacity Not Published 10.57 gal Front Axle Fluid Capacity Not Published 2.24 gal ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm 540 rpm @ 2058 engine rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT I & II with telescopic stabilizers & flex links Category I & II adjustable, with telescopic stabilizers Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) Not Published Not Published Lift Control Type Position control Position & draft control ▶ Transmission & DrivetrainTransmission Type Full synchromesh with forward/reverse synchro shuttle and constant-mesh range Full constant mesh No. of Speeds 12F / 12R 8F / 2R Max Travel Speed (Forward) 17.9 mph 17.6 mph Max Travel Speed (Reverse) Not Published 7.53 mph Clutch Dual dry with cerametallic lining Dual Differential Lock & Limited Slip Options Not Published Foot-operated differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering with tilt steering wheel Hydrostatic power steering Brakes Fully-enclosed, 7-in diameter, dry disc Fully enclosed dry disc Seat Suspension & Adjustability Adjustable seat with contoured cushions, armrests and a soft-coil suspension mComfort mechanical suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 74.8 in 82.6 in Wheelbase 77.9 in 76.7 in Ground Clearance 15.2 in Not Published Min. Turn Radius without Brakes 12.8 ft (3.9 m) 147.63 in Height to Top of ROPS Not Published 93.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 136.6 in 127.0 in ▶ WeightTractor Weight (Base) 5,390 lb 5,192 lb (operating weight) Weight with ROPS and Loader 6,690 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural or R4 Industrial Industrial (standard); Agri (optional) R1 Agricultural - Front 9.5 x 20 9.5X16 R1 Agricultural - Rear 14.9 x 28 12.4X28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 10.5/80 x 18 Not Published R4 Industrial - Rear 16.9 x 24 16.9X24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style quick-attach coupler Skid-steer style quick-attach coupler Loader Model 5155-4L (front loader); 65B (rear backhoe) 4550-4L Loader Lift Height 122 in 116.6 in Loader Lift Capacity (Full Height) 3,100 lb 2,866 lb at pivot pins to full height Loader Breakout Force 5,200 lb 4,978 lb at pivot pins ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty 7-Year Limited Powertrain Warranty
