▶ EngineEngine Manufacturer Mahindra Kubota Engine Model DH55 V3307-DI Engine Type Turbocharged, direct injection, liquid-cooled diesel 4-cylinder inline, direct injected diesel No. of Cylinders 4 4 Displacement 166.2 in³ 203 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 55 hp Not Published PTO Power 47 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published 8 in dry, dual element Fuel System Direct injection Direct injection Alternator 55 A ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 8.71 gpm 11.0 gpm Steering Flow 4.62 gpm 6.1 gpm Total Hydraulic Flow 13.3 gpm 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow 13.3 gpm 17 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 17.1 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity Not Published 8.5 qt Crankcase Capacity Not Published 11.6 qt Transmission / Hydraulic System Capacity Not Published 10.6 gal Front Axle Fluid Capacity Not Published 8.5 qt ▶ PTO & HitchPTO Type Independent Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT I & II with telescopic stabilizers & flex links Category II Hitch Lift Capacity Not Published 4,189 lb Hitch Lift Capacity (at 24”) 3,748 lb 3,307 lb Lift Control Type Position control Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type Full synchromesh with forward/reverse synchro shuttle and constant-mesh range Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 12F / 12R 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) 17.9 mph 18 mph Max Travel Speed (Reverse) Not Published 18.0 mph Clutch Dual dry with cerametallic lining Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Not Published Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Power steering with tilt steering wheel Hydrostatic power steering Brakes Fully-enclosed, 7-in diameter, dry disc Multiple wet disc, mechanical Seat Suspension & Adjustability Adjustable seat with contoured cushions, armrests and a soft-coil suspension Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Not Published 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 136.6 in 2WD: 140.4 in; 4WD: 135.6 in Overall Width 74.8 in 73.2 in Wheelbase 77.9 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance 16.4 in 15.4 in Min. Turn Radius without Brakes 10.8 ft 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS Not Published 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 99.8 in ▶ WeightTractor Weight (Base) 5,390 lb 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader 6,690 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural or R4 Industrial Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 9.5 x 20 2WD: 7.50-16; 4WD: 9.5-24 R1 Agricultural - Rear 14.9 x 28 16.9-28 R3 Turf - Front Not Published 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear Not Published 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front 10.5/80 x 18 12.5/80-18 (4WD) R4 Industrial - Rear 16.9 x 24 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style quick-attach coupler LA1153: two-lever quick coupler Loader Model 5155-4L (front loader); 65B (rear backhoe) LA1153 Loader Lift Height 5155-4L: 122 in LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) 5155-4L: 3,100 lb Not Published Loader Breakout Force 5155-4L: 5,200 lb Not Published ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty Not Published
