▶ EngineEngine Manufacturer Mahindra Mahindra Engine Model DH55 Not Published Engine Type Four-stroke, turbocharged, direct injection, water-cooled diesel 5145: Four-stroke, naturally aspirated, direct injection, water-cooled diesel; 5155: Four-stroke, turbocharged, direct injection, water-cooled diesel No. of Cylinders 4 4 Displacement 166.2 in³ 166.2 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 55 hp 45 hp PTO Power 47 hp 38 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Not Published Air Cleaner Not Published Not Published Fuel System Direct injection Not Published Alternator 55 A 55 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 8.71 gpm 8.71 gpm Steering Flow 4.62 gpm 4.62 gpm Total Hydraulic Flow 13.3 gpm Not Published Overall Hydraulic Pump Flow 13.3 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves One One No. of Optional Remote Valves One (optional second rear valve) One (optional second rear valve) ▶ Fluid CapacityFuel Tank Capacity 17.1 gal 17.1 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm 540 rpm @ 2300 rpm; 540E @ 1725 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT I & II with telescopic stabilizers & flex links CAT I & II w/ Telescopic Stabilizers & Flex Links Hitch Lift Capacity Not Published 3,748 lb Hitch Lift Capacity (at 24”) 3,748 lb Not Published Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Full synchromesh with forward/reverse synchro shuttle and constant-mesh range Full synchromesh with forward/reverse synchro shuttle and constant-mesh range No. of Speeds 12F / 12R 12F / 12R Max Travel Speed (Forward) 17.9 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dual dry with cerametallic lining Dual Dry with Cerametallic Lining Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering with tilt steering wheel Tilt, power-assisted steering Brakes Fully-enclosed, 7-in diameter, dry disc Fully-enclosed, 7-in Diameter, Dry Disc Seat Suspension & Adjustability Adjustable seat with contoured cushions, armrests and a soft-coil suspension Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 74.8 in Not Published Wheelbase 77.9 in 77.9 in Ground Clearance 16.4 in 5145: 15.2 in; 5155: 16.4 in Min. Turn Radius without Brakes 10.8 ft (3.29 m) 12.8 ft (3.9 m) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 136.6 in Not Published ▶ WeightTractor Weight (Base) 5,390 lb 5,390 lb Weight with ROPS and Loader 6,690 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural or R4 Industrial Not Published R1 Agricultural - Front 9.5 x 20 9.5 x 20 R1 Agricultural - Rear 14.9 x 28 14.9 x 28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 10.5/80 x 18 10.5/80x18 R4 Industrial - Rear 16.9 x 24 16.9 x 24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style quick-attach coupler Not Published Loader Model 5155-4L (front loader); 65B (rear backhoe) 5155-4L Loader Lift Height 122 in 5155-4L: 122 in Loader Lift Capacity (Full Height) 3,100 lb 5155-4L: 3,100 lb Loader Breakout Force 5,200 lb 5155-4L: 5,200 lb ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty 5-year, 3000-hour limited powertrain warranty
