▶ EngineEngine Manufacturer Mahindra Kubota Engine Model Not Published V3307-CR-TE4 Engine Type Turbocharged and intercooled, direct injection diesel 4-cylinder, turbocharged, common-rail diesel No. of Cylinders 3 4 Displacement 161.5 in³ 203 in³ Rated Engine Speed 2100 rpm 2400 rpm Engine Power (Gross) 70 hp 71.1 hp PTO Power 61 hp 60 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Turbocharged and intercooled, direct injection, common-rail Common rail direct injection Alternator 55 A, 12 V 130 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11.2 gpm 16.7 gpm Steering Flow 4.6 gpm 6.3 gpm Total Hydraulic Flow 15.8 gpm (11.2 + 4.6, computed) 23.0 gpm (16.7 + 6.3, computed) Overall Hydraulic Pump Flow Not Published 23.0 gpm (16.7 + 6.3, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 (SCD) No. of Optional Remote Valves Not Published Max. 3 ▶ Fluid CapacityFuel Tank Capacity 17.1 gal 23.8 gal Coolant Capacity Not Published 10.6 qt Crankcase Capacity Not Published 12.7 qt Transmission / Hydraulic System Capacity Not Published 49.6 qt Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm @ 2059 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT I and II with telescopic stabilizers Category I / II Hitch Lift Capacity 3,968 lb Not Published Hitch Lift Capacity (at 24”) Not Published 3,307 lb Lift Control Type Position and draft control Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type Constant mesh with forward/reverse synchro shuttle Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) No. of Speeds 8F/8R F12 / R12 (option: F18 / R18 with creep) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dual dry with cerametallic lining Multiple wet disc Differential Lock & Limited Slip Options Not Published Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Bevel gear type (4WD, mechanical on-the-go 4WD clutch) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 77.3 in (5570 2WD); 81 in (5570 4WD) 75.6 in Wheelbase Not Published 84.1 in Ground Clearance Not Published 18.1 in (front axle crop clearance) Min. Turn Radius without Brakes 14 ft (5570 2WD); 15.7 ft (5570 4WD) 11.8 ft Height to Top of ROPS 103.3 in (5570 2WD); 99.7 in (5570 4WD) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 101 in Overall Length 138.3 in (5570 2WD); 145 in (5570 4WD) 144 in ▶ WeightTractor Weight (Base) 5,557 lb (5570 2WD, operating weight); 6,302 lb (5570 4WD, operating weight) 5,952 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag (5570 2WD); Ag, Industrial (5570 4WD) Standard: 320/70R24 front, 420/75R34 rear R1 Agricultural - Front 9.5Lx15 (5570 2WD); 11.2x24 (5570 4WD) 320/70R24 R1 Agricultural - Rear 16.9x28 (5570 2WD); 16.9x30 (5570 4WD) 420/75R34 R3 Turf - Front Not Published 9.50-24 R3 Turf - Rear Not Published 18.4-26 R4 Industrial - Front 12.5/80x18 (5570 4WD) 14-17.5 R4 Industrial - Rear 19.5x24 (5570 4WD) 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 5565-2L (5570 2WD); 5565-4L (5570 4WD) LA1154A Loader Lift Height 5565-2L: 123 in; 5565-4L: 128 in LA1154A: 133.0 in (height position); 117.6 in (power position) Loader Lift Capacity (Full Height) 5565-2L: 3,250 lb; 5565-4L: 3,000 lb LA1154A: 2,674 lb (height position); 2,928 lb (power position) Loader Breakout Force 5565-2L: 5,300 lb; 5565-4L: 4,825 lb LA1154A: 4,079 lbf (height position); 5,128 lbf (power position) ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours, all usage
