▶ EngineEngine Manufacturer Mahindra Kubota Engine Model VNEM 363 V2403-CR-E4-GL5 Engine Type Turbocharged and intercooled, common-rail, liquid-cooled diesel (Tier 4 Final) Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 3 4 Displacement 161.7 in³ 148.5 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 62 hp 62 hp PTO Power 53.5 hp 53 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element Fuel System Common rail direct injection Electronic Common Rail System (CRS) Alternator Power Shuttle: 55 A; Power Shuttle Cab: 140 A; Shuttle: 55 A 45 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 11.1 gpm 9.4 gpm Steering Flow 4.6 gpm 4.7 gpm Total Hydraulic Flow 15.7 gpm 14.1 gpm Overall Hydraulic Pump Flow 15.7 gpm 14.1 gpm Hydraulic System Type Open center, position and draft control, telescoping stabilizers and flex links Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Shuttle: single auxiliary valve; Power Shuttle: double auxiliary valves Not Published No. of Optional Remote Valves Shuttle: 2nd and 3rd valves; Power Shuttle: 3rd valve Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 13.5 gal Coolant Capacity Not Published 8.7 qt Crankcase Capacity Not Published 9.9 qt Transmission / Hydraulic System Capacity Not Published 11.9 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type 2 speed independent push button type 1 PTO (wet clutch) Live independent (hydraulic clutch) PTO Rear 540 @ 1993 rpm and 540E @ 1469 rpm 540 rpm @ 2400 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch CAT I & II SAE Category I & II Hitch Lift Capacity Not Published 3,858 lb Hitch Lift Capacity (at 24”) 5,952 lb 2,976 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type Full synchro mesh speed and constant mesh range Hydrostatic transmission No. of Speeds 15F / 15R 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 21.4 mph 16.8 mph Max Travel Speed (Reverse) Not Published 15.2 mph Clutch Shuttle: Mechanical shuttle with dry clutch; Power Shuttle: Power shuttle with wet clutch and torsional damper Not Published Differential Lock & Limited Slip Options Not Published Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering with tiltable steering column Hydrostatic power steering Brakes Oil immersed brakes, lever actuated parking brake Wet disc type, mechanically activated Seat Suspension & Adjustability mComfort seat with contoured cushions, armrests and adjustable legroom; air-ride suspension seat in cab Suspension seat with swivel function Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 82 in 67.3 in Wheelbase 87.4 in 75.4 in Ground Clearance 15.5 in 15.4 in Min. Turn Radius without Brakes 12.5 ft (3.8 m) 9.2 ft (with brake applied) Height to Top of ROPS 106 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 115 in Not Applicable Overall Length 152.7 in 135.0 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 6,548 lb (6065 Power Shuttle); 7,495 lb (6065 Power Shuttle Cab); 6,416 lb (6065 Shuttle) 3,990 lb Weight with ROPS and Loader 8,428 lb (6,548 + 1,880, computed; 1,604.8 gal loader shipping weight) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Industrial Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 11.2 x 24 9.5-16 R1 Agricultural - Rear 16.9 x 30 14.9-26; 13.6-28 R3 Turf - Front Not Published 29X12.50-15 R3 Turf - Rear Not Published 44X18-20 R4 Industrial - Front 43 x 16-20 10-16.5 R4 Industrial - Rear 18.4-28 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer tool carrier system for ultra-fast attachments hookup 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model 6075L LA1055 Loader Lift Height Loader 6075L: 133 in 112.7 in (at pivot pin) Loader Lift Capacity (Full Height) Loader 6075L: 3,609 lb (at pivot pin) 2,361 lb (at pivot pin) Loader Breakout Force Loader 6075L: 5,000 lb 3,171 lbf ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
