▶ EngineEngine Manufacturer Mahindra Mahindra Engine Model VNEM 363 DH55 Engine Type Turbocharged and intercooled, common-rail, liquid-cooled diesel (Tier 4 Final) Four-stroke, turbocharged, direct injection, water-cooled diesel No. of Cylinders 3 4 Displacement 161.7 in³ 166.2 in³ Rated Engine Speed 2100 rpm 2300 rpm Engine Power (Gross) 62 hp 55 hp PTO Power 53.5 hp 47 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Not Published Fuel System Common rail direct injection Direct injection Alternator Power Shuttle: 55 A; Power Shuttle Cab: 140 A; Shuttle: 55 A 55 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11.1 gpm 8.71 gpm Steering Flow 4.6 gpm 4.62 gpm Total Hydraulic Flow 15.7 gpm 13.3 gpm Overall Hydraulic Pump Flow 15.7 gpm 13.3 gpm Hydraulic System Type Open center, position and draft control, telescoping stabilizers and flex links Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Shuttle: single auxiliary valve; Power Shuttle: double auxiliary valves One No. of Optional Remote Valves Shuttle: 2nd and 3rd valves; Power Shuttle: 3rd valve One (optional second rear valve) ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 17.1 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type 2 speed independent push button type 1 PTO (wet clutch) Independent PTO Rear 540 @ 1993 rpm and 540E @ 1469 rpm 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT I & II CAT I & II with telescopic stabilizers & flex links Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 5,952 lb 3,748 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type Full synchro mesh speed and constant mesh range Full synchromesh with forward/reverse synchro shuttle and constant-mesh range No. of Speeds 15F / 15R 12F / 12R Max Travel Speed (Forward) 21.4 mph 17.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Shuttle: Mechanical shuttle with dry clutch; Power Shuttle: Power shuttle with wet clutch and torsional damper Dual dry with cerametallic lining Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering with tiltable steering column Power steering with tilt steering wheel Brakes Oil immersed brakes, lever actuated parking brake Fully-enclosed, 7-in diameter, dry disc Seat Suspension & Adjustability mComfort seat with contoured cushions, armrests and adjustable legroom; air-ride suspension seat in cab Adjustable seat with contoured cushions, armrests and a soft-coil suspension Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 82 in 74.8 in Wheelbase 87.4 in 77.9 in Ground Clearance 15.5 in 16.4 in Min. Turn Radius without Brakes 12.5 ft (3.8 m) 10.8 ft (3.29 m) Height to Top of ROPS 106 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 115 in Not Published Overall Length 152.7 in 136.6 in ▶ WeightTractor Weight (Base) 6,548 lb (6065 Power Shuttle); 7,495 lb (6065 Power Shuttle Cab); 6,416 lb (6065 Shuttle) 5,390 lb Weight with ROPS and Loader 8,428 lb (6,548 + 1,880, computed; 1,604.8 gal loader shipping weight) 6,690 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Industrial R1 Agricultural or R4 Industrial R1 Agricultural - Front 11.2 x 24 9.5 x 20 R1 Agricultural - Rear 16.9 x 30 14.9 x 28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 43 x 16-20 10.5/80 x 18 R4 Industrial - Rear 18.4-28 16.9 x 24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer tool carrier system for ultra-fast attachments hookup Skid-steer style quick-attach coupler Loader Model 6075L 5155-4L (front loader); 65B (rear backhoe) Loader Lift Height Loader 6075L: 133 in 122 in Loader Lift Capacity (Full Height) Loader 6075L: 3,609 lb (at pivot pin) 3,100 lb Loader Breakout Force Loader 6075L: 5,000 lb 5,200 lb ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty 5-year limited powertrain warranty
