▶ EngineEngine Manufacturer Mahindra Kubota Engine Model VNEM 373 V3307-CR-TE4 Engine Type Turbocharged and intercooled, common-rail, liquid-cooled diesel (Tier 4 Final) Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 3 4 Displacement 161.7 in³ 203 in³ Rated Engine Speed 2100 rpm 2400 rpm Engine Power (Gross) 71 hp 72.1 hp PTO Power 61 hp 62 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Common rail direct injection Common Rail System (CRS) Alternator Power Shuttle: 55 A; Power Shuttle Cab: 140 A 45 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 11.1 gpm 11.0 gpm Steering Flow 4.6 gpm 6.1 gpm Total Hydraulic Flow 15.7 gpm 17.1 gpm Overall Hydraulic Pump Flow 15.7 gpm 17.1 gpm Hydraulic System Type Open center, position and draft control, telescoping stabilizers and flex links Open Center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves Double auxiliary valves 1 (SCD) No. of Optional Remote Valves 3rd valve 2nd, 3rd (optional) ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 18.5 gal Coolant Capacity Not Published 8.5 qt Crankcase Capacity Not Published 12.7 qt Transmission / Hydraulic System Capacity Not Published 14.8 gal Front Axle Fluid Capacity Not Published 5.8 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type 2 speed independent push button type 1 PTO (wet clutch) Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 @ 1993 rpm and 540E @ 1469 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT I & II I / II Hitch Lift Capacity Not Published 4,189 lb Hitch Lift Capacity (at 24”) 5,952 lb 3,307 lb Lift Control Type Position and draft control Position, Draft (Top Link Sensing) & Mixed Control ▶ Transmission & DrivetrainTransmission Type Full synchro mesh speed and constant mesh range Hydraulic-shuttle (F8/R8), fully synchronized (4-speed main) No. of Speeds 15F / 15R F8/R8 Max Travel Speed (Forward) 21.4 mph 18.8 mph Max Travel Speed (Reverse) Not Published 18.5 mph Clutch Power shuttle with wet clutch and torsional damper Multiple wet disc Differential Lock & Limited Slip Options Not Published Front: limited slip differential; Rear: mechanical ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Hydrostatic power steering with tiltable steering column Hydrostatic power steering Brakes Oil immersed brakes, lever actuated parking brake Mechanical wet disc Seat Suspension & Adjustability mComfort seat with contoured cushions, armrests and adjustable legroom; air-ride suspension seat in cab Suspension seat, adjustable (travel, suspension tension, backrest tilt, armrests); optional air-suspension seat on cab models Front Axle Type Not Published Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,290 lb (6,615 lb with loader) Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 82 in 73.0 in Wheelbase 87.4 in 83.1 in Ground Clearance 15.5 in 14.3 in Min. Turn Radius without Brakes 12.5 ft (3.8 m) 11.8 ft Height to Top of ROPS 106 in 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 115 in n/a (ROPS model) Overall Length 152.7 in 138.0 in ▶ WeightTractor Weight (Base) 6,548 lb (6075 Power Shuttle); 7,495 lb (6075 Power Shuttle Cab) 5,027 lb Weight with ROPS and Loader 8,428 lb (6,548 + 1,880, computed; 1,604.8 gal loader shipping weight) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Industrial Standard: 9.5-24 front, 16.9-30 rear R1 Agricultural - Front 11.2 x 24 9.5-24 R1 Agricultural - Rear 16.9 x 30 16.9-30 R3 Turf - Front Not Published 9.5-24 or LSW305-521 R3 Turf - Rear Not Published 18.4-26 or LSW570-648 R4 Industrial - Front 43 x 16-20 14-17.5 R4 Industrial - Rear 18.4-28 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer tool carrier system for ultra-fast attachments hookup LA1154A: 2-Lever Quick Coupler Loader Model 6075L LA1154A Loader Lift Height Loader 6075L: 133 in Height position: 132.7 in; Power position: 117.2 in Loader Lift Capacity (Full Height) Loader 6075L: 3,609 lb (at pivot pin) Height position: 2,469 lb; Power position: 2,928 lb Loader Breakout Force Loader 6075L: 5,000 lb Height position: 4,230 lbf; Power position: 5,354 lbf ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
