▶ EngineEngine Manufacturer Daedong Mahindra Engine Model Not Published Not Published Engine Type Turbo-charged, indirect injection Four stroke, direct injection, turbo-charged and intercooled diesel No. of Cylinders 4 3 Displacement 148.6 in³ 161.7 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 59 hp 55 hp PTO Power 48.5 hp 45 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Direct injection, turbocharged and intercooled (mCRD common rail) Alternator 50 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11 gpm 10.6 gpm Steering Flow 5.4 gpm 4.5 gpm Total Hydraulic Flow Not Published 15.1 gpm (10.6 + 4.5, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open Center with position and draft control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 3 1 (2 spool optional) ▶ Fluid CapacityFuel Tank Capacity 18.5 gal 17.1 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm @ 2600 rpm 540 rpm @ 2059 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 2, with telescopic check chains CAT I and II with telescopic stabilizers Hitch Lift Capacity 3527 lb 3968 lb Hitch Lift Capacity (at 24”) Not Published Not Published Lift Control Type Position and draft control Position and draft control ▶ Transmission & DrivetrainTransmission Type Sync, shuttle w/ part synchromesh Constant mesh with forward/reverse synchro shuttle No. of Speeds 12F / 12R 8F/8R Max Travel Speed (Forward) 20.0 mph Not Published Max Travel Speed (Reverse) 20.5 mph Not Published Clutch Single plate, dry Dual dry with cerametallic lining Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic/Tiltable Hydrostatic power steering Brakes Wet Disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 141.3 in 138.4 in (5555 2WD); 141.2 in (5555 4WD) Overall Width 71.5 in 75.3 in (5555 2WD); 79 in (5555 4WD) Wheelbase Not Published Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 12.5 ft 11.6 ft (5555 2WD); 13.75 ft (5555 4WD) Height to Top of ROPS Not Published 92 in (5555 2WD); 94.5 in (5555 4WD) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.2 in Not Published ▶ WeightTractor Weight (Base) 4850 lb 5379 lb (5555 2WD); 6039 lb (5555 4WD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Ag (5555 2WD); Ag, Industrial (5555 4WD) R1 Agricultural - Front 9.5x20 7.5x16 (5555 2WD); 9.5x24 (5555 4WD) R1 Agricultural - Rear 14.9x28 14.9x28 R3 Turf - Front LSW305-521 Not Published R3 Turf - Rear LSW570-648 Not Published R4 Industrial - Front 10.5/80x18 12.5/80x18 (5555 4WD) R4 Industrial - Rear 18.4x24 16.9x24 (5555 4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model ML161 5565-2L (5555 2WD); 5565-4L (5555 4WD) Loader Lift Height ML161: 115.4 in 5565-2L: 123 in; 5565-4L: 128 in Loader Lift Capacity (Full Height) ML161: 3122 lb 5565-2L: 3,250 lb; 5565-4L: 3,000 lb Loader Breakout Force ML161: 5225 lb 5565-2L: 5,300 lb; 5565-4L: 4,825 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
